33ton Excavator With ce

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	CT
Model Number	CT330-8C	Condition	New
Moving Type	Crawler Excavator	Operating Weight	32000kg
Bucket capacity	1.4CBM	Maximum Digging Height	10078MM
Maximum Digging Depth	6460MM	Machine Weight	32000kg
Max Digging Radius	360	Rated Speed	5.0/3.1km/h
Certification	CE	After-sales Service Provided	No overseas service provided

1)Original ISUZU 6BG1TRP-01 engine
2)Japanese Kawasaki main pump aa swing motor
3)1.4CBM bucket
4)Japanese KYB valve, trave

Excavator model	CT330-8C with cabin
Specification of CT330-8c with cabin
Operate weight kg		32000
Bucket capacity M3		1.4
Engine model		ISUZU 6BG1TRP-01
Engine power (kw)		184kw/2000rpm
Swing spreed (rpm)		10
Ground pressure (Kpa)		59.6
Travel speed (km/h)		5.0/3.1
Gradeability (°)		30
Bucket digging force (KN)		227
Fuel tank capacity(L)		630
Hydraulic tank capacity(L)		260
Main dimensions
Upperstrcuture witdth (mm)		3195
Undercarriage width (mm)		3190
Cabinet hight (mm)		3125
Rear swing radius (mm)		3425
Ground clearance (mm)		500
Working range
Max.digging reach (mm)		11077
Max.digging depth (mm)		7362
Max.digging height (mm)		10078
Max.dumping height (mm)		7382
Max.vertical wall digging depth (mm)		6460
Min,swing radius (mm)		4348
Standard Equipment
Japanese Kawasaki main pump , swing motor
Japanese KYB valve, traveling motor
Italian pilot control lever

Warranty,Payment and Delivery
Warranty Term: 1200 working hours or 1 year, whichever come first
Payment Term: 100% T/T or Irrevocable L/C payable at sight
Time of delivery: 30 days for models with standard equipment, after receipt of L/C or 30% T/T down payment.
