sawdust with moisture 40% powder carbon material and steel material rotary drum dryer

 Working Theory of Rotary dryer

1. What the rotary dryer can be used for ?
This dryer can dry many kinds of materials which contain moisture, such as coal, coal slurry, slag, industrial waste, and clay stone. They are widely used in building materials, metallurgy, and chemical industry.

 2. What is the rotary dryer consist of?

The dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.

 3. Can I use the coal or gas as the heating source?

Yes, you can use coal, gas, electricity, oil and wind power to heat the dryer machine.

 4. How the rotary dryer to work?

The raw material plate is arranged conveniently to allow adjustable angle positions. The material to be dried is inserted to the rotary cylinder through the raw material plate. Hot air flows within the cylinder causing the separation of water from the material by converting it into vapor which is discharged into the atmosphere. At this point, the material becomes dry.

 Technical Feature:

rotary dryer material :Q345,thickness:18mm

reducer: Zibo of Shandong province

bearing : tile-roofed house bearing

input and outpu conveyor:

width 500mm,length10m screw conveyor

 Complete sets of equipment supply list:

rotary dryer: main rotary body,before roller ring,after roller ring,gear,pinion,input and output parts,reducer,motor, foundation bolt

layout plan drawing,foundation drawing of each machine
