Construction tools metal bender machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port shanghai guangzhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	GLORY	Model Number	GW50
Machine Type	Beading Machine	Raw Material	Other, iron and steel
Material / Metal Processed	Carbon Steel	Power	Other, electric
Automation	Automatic	Extra Services	Machining
Certification	ISO 9001:2000	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

metal bender machine
1.High efficiency, simple operation
2. Perfect quality and compititive price
3. professional supplier

Construction tools metal bender machine

Metal bender machine specific introduction

• GW series steel bar bender adopts the fully enclosed GEAR BOX for less distortions even under the condition of heavy loads.

• GEAR SHAFTS, WORKING DISK, STOP GAUGE, SADDLES, PILE HEAD and PILE HEAD BUSHES are made of forged high-quality alloyed steel with proper heat (quenching/ tempering/ high frequency) and 2 mm thick external case to ensure high performances also under heavy loads and long working life.
• TWO LIMIT-SWITCH to ensure the accuracy of the bending angle.

Metal bender machine parameter

Steel bar bender	GW42 (3 switch)	Bending rebar diameter:φ6-φ42mm (A3φ6-36(Class Ⅱdeformed steel )mm Working disk diameter:φ380mm Worktop length:800mm Worktop width:800mm Main shaft revolving speed:7r/min Adjustable speed:5-10r/min Motor power:3kw Motor speed:1420r/min Overall size:960×880×950 Gross weight:280kg
steel bar bender	GW40	Bending diameter: round steel: φ10 to 40mm Level II deformed steel: φ8 to 36mm Diameter of working disc: φ350mm Speed of working disc: 10r/min (low speed: 5r/min) Motor power: 3KW Overall size: 860x810x800mm Gross weight: 230KG
steel bar bender	GW40B heavy duty	Bending diameter: round steel: φ10 to 40mm Level II deformed steel: φ8 to 36mm Diameter of working disc: φ350mm Speed of working disc: 10r/min (low speed: 5r/min) Motor power: 3KW Overall size: 970x860x800mm Gross weight: 320KG
steel bar bender	GW50	Bending diameter: round steel: φ10 to 50mm Level II deformed steel: φ6 to 36mm Diameter of working disc: φ400-380mm Speed of working disc: 14r/min (low speed: 7r/min) Motor power: 4KW Overall size: 1120x830x760mm Gross weight: 360KG
steel bar bender	GW50A heavy duty	Bending diameter: round steel: φ10 to 50mm Level II deformed steel: φ6 to 36mm Diameter of working disc: φ400-380mm Speed of working disc: 14r/min (low speed: 7r/min) Motor power: 4KW Overall size: 1120x890x800mm Gross weight: 380KG

Expoded view

Our service

1. 24 hours service for pre-sales and after sales,

2. Warm welcome honest and respectable business relation as our agent,

3. We supply OEM and ODM service,

4. Warm welcome your visit to our factory.
