Home > Products > Vibrating Sieve for Food Industry > High efficiency vertical vibrating sieve for powder and particle
High efficiency vertical vibrating sieve for powder and particle
- any port in China
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | HENG SHUN | |
| Model Number | HY-1000-1S | Type | Grain Processing Equipment |
Product Description
Welcome to our vertical vibrating sieve page!
This type is specially designed for separating the flour for removing impurities such as insects, sack threads etc. from the flour to make good quality biscuits, cake, noodle or bread. For you only by telling us the screen size and production capacity per hour you demand, the proper equipment size can be recommended as soon as possible.
This type of vertical vibrating sieve enjoy big advantage features to suit powder screening:
1. Vertical type design, fine flour is directly discharged after screening with large production capacity
2. Manufactured by stainless steel 304 which are in line with the requirements of GMP.
3. Can be directly installed between the raw materials barrel and the storage drums, save space.
4. Motor force can be adjusted to optimize discharge pattern and screening result.
5. Available in 600mm through 1200mm diameter depend on capacity demanded.
Let’s see more machine details by pictures:
Technical Parameters for you to choose suitable machine size:
Model | Motor | Effective diameter of the screen (mm) | Layer | |||||
HP | KW | Voltage (V) | Frequency | Speed | Largest vibration force (N) | |||
HY-600 | -- | 0.18 | 380/415 | 50/60 | 1500 | 3000 | 550 | 1 |
HY-800 | -- | 0.18 | 380/415 | 50/60 | 1500 | 3000 | 760 | 1 |
HY-1000 | -- | 0.25 | 380/415 | 50/60 | 1500 | 5000 | 930 | 1 |
HY-1200 | 1/2 | 0.37 | 380/415 | 50/60 | 1500 | 8000 | 1130 | 1 |
NOTE:
1. Working power and layer demanded
The common voltage and frequency of this rotary separator is 3 Phase, 380V, 50Hz, for other voltage or frequency, we could also customize motor for you.
2. Other service
At Hengyu, we supply circular vibrating sieve, linear vibrating screen, vibrating feeder, lifting machine, conveyor equipment, dozens of series. If you cannot find right machine you are looking for from our website, please phone or email us, we happy to adjust and modify machines whatever design or dimension to meet the appropriate requirements and assembly conditions to optimize the screening result.
Our certifications:
Please kindly contact with us for the details as per your application.
We'd like to supply you the best solution.
