Electric Mixing Concrete Pump
- 2000 Set / Sets per Month
- Qingdao
- T/T
You May Like
-
Hot Sale Concrete Pump Towable With Concrete Mixer
-
Hot Sale Ready Mix Concrete Pump With Mixer From China
-
Hot Sale Concrete Mixing Pump With Concrete Mixer
-
High Quality Concrete Pump Machine Price In China
-
China Professional Concrete Pumping Equipment Supplies
-
Sell Concrete Pump And Concrete Mixing Pump With High Quality
Product Details
| Condition | New | Power Type | Diesel | |
| Place of Origin | Henan, China | Brand Name | UNIQUE | |
| Model Number | JBT30 | Power(W) | 30kw | |
| Weight | 3500kg | Dimension(L*W*H) | 4300*2060*3680(mm) | |
| Certification | ISO | Warranty | More than one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Electric Mixing Concrete Pump
Description of JBT30 Electric Mixing Concrete Pump :
Concrete mixer pump is a new kind of engineering equipment of the combination of concrete mixer and concrete pump. It uses dual-cylinder hydraulic pumping system, small size and operating space and large concrete pouring and excellent characteristics of the mature and stable performance. The product is suitable for 2 to 12-storey small building construction, and a variety of cave, roads, railway tunnels, water conservancy and hydropower engineering, geological hazards slope treatment works.
Parameters of JBT30 Electric Mixing Concrete Pump :
Max theoretical concrete conveying capacity | 30m3/h |
Distribution valve model | S tube valves |
Hopper capacity * filling height | 500L* 1200mm |
Pump motor power | 30kw |
Winding motor power | 4kw |
Hydraulic circuit form | Open circuit |
Rated speed | 1480Rmp |
Oil tank volume | 170L |
Weight | 3500kg |
Concrete pumping pressure | 9Mpa |
Concrete cylinder size * length | 180mm*800mm |
Discharge mouth diameter | 180mm |
Mixing motor power | 3*2kw |
Water pump motor power | 550w |
Max aggregate diameter | Pebble: 40mm |
Gravel: 30mm | |
Voltage | 380v |
Dimension(L*W*H) | 4300*2060*3680(mm) |
UNIQUE was founded in 1973, more than 40 years dedicated to building construction enterprises make the most suitable products and services.
Service and Support
UNIQUE has the 12 workshops to produce every part of concrete mixing plants and we can produce spare parts to delivery thern to you within 2 days.
