Mining Machine/Laboratory leaching equipment
- Qingdao China
- T/T Credit Card
You May Like
Product Details
| Condition | New | Production Capacity | depend on the model | |
| Power(W) | depend on the model | Place of Origin | Shandong, China | |
| Brand Name | Xinhai | Model Number | XH | |
| Dimension(L*W*H) | depend on the model | Certification | ISO 9001, CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Laboratory leaching equipment1.Powerful stirring capability
2.Strong circulation ability of pulp and reagent
3.ISO 9001, CE
Laboratory leaching equipment — Product feature
High impeller speed, strong mixing capable of slurry and reagent
Laboratory leaching equipment — Product application
It is widely used for geological, metallurgy, building materials, mining, chemical and other industries to add reagent.
Laboratory leaching equipment — Product principle
Through the impeller in the groove rotates to drive the pulp flow, make the particle to fully contact with reagent.
Laboratory leaching equipment — Technology parameter
| Item | Unit | Parameter |
| Specification of agitator | L | 1.5,3,5.5 |
| Volume of agitation tank | L | 1.5,3,5.5 |
| Diameter of impeller | (mm) | φ31 |
| Diameter of impeller | (mm) | φ39 |
| Diameter of impeller | (mm) | φ48 |
| Rotating speed of the impeller | (r.p.m) | 950 |
| Rotating speed of the impeller | (r.p.m) | 1400 |
| Rotating speed of the impeller | (r.p.m) | 1750 |
| Circular velocity of impeller | (m/s) | 1.54,2.27,2.84 |
| Circular velocity of impeller | (m/s) | 1.94,2.86,3.57 |
| Circular velocity of impeller | (m/s) | 2.39,3.52,4.40 |
| Motor model | JW6314 | |
| Motor power | (kw) | 0.18 |
| Rotating speed of the impeller | (r.p.m) | 1400 |
| External dimension(L) | (mm) | 505 |
| External dimension (W) | (mm) | 304 |
| External dimension (H) | (mm) | 633 |
| Weight | (kg) | 40 |
Group Introduction
Xinhai Group founded in 1993 has grown into the industry group involving mineral processing, wearable rubber, mining investment and LFC Machinery after twenty years development. We have been always committed to providing customers with professional, perfect, efficient equipment and solutions. The whole solution we provide for you with the core of reliable & efficient mineral processing schemes and environmental-protection & energy-saving tailings dry stacking, makes us stand up in every EPC bid.
Our company has many other products for you reference as following:
1.Crushing Machinery
2.Grinding Machinery
3.Screening Machinery
4.Flotation Machinery
5.Magnetic Equipment
6.Thickening Equipment
7.Filtration Equipment
8.Gravity Separation Equipment
......
Warmly welcome to visit our factory and company any time you like it !
