Hoist Type Wood Log Charcoal Kiln Manufacturer

 Structure of our wood log charcoal kiln

This hoist wood log charcoal kiln is the cylinder shape. The whole single furnace consists of main furnace(outer stove), carbon basket(inner stove), fume extraction tube, smoking purification system and hoisting equipment.

Features of our hoist wood log charcoal kiln:

1. easy to operate and maintain, higher safety, energy saving.

2. High carbonization ratio, no smoke, little pollution, high efficiency.

3.This wood carbonization furnace is our newly developed charcoal making furnace, which can dry the mateiral with the

the superfluous energy produced in the process of carbonization. 6-8hours per stove and the inner basket can work

continuously by shift.

4. the hoist wood log charcoal machine has smoke purifying system, smoke can be filtered before be discharged to air.

Model

Capacity

Note

Power

Weight

Temperature

Model-1

1-3T/day

1  outer  stove+3  inner  stoves

No

3.8T

420-480° C

Model-2

4-6T/day

2  outer  stove+6  inner  stoves

No

7.6T

420-480° C

Model-3

7-9T/day

3  outer  stove+9  inner  stoves

0.75

10.8T

420-480° C

Model-4

10-12T/day

4  outer  stove+12  inner  stoves

0.75

14.4T

420-480° C

Type:

Dry  distillation  type.

Raw  materials:

wood  log, briquette wood, tree  branches, nut  shells, bamboo, ect.

Environment:

Totally  No  pollution, it  will  not  produce  any  smoke.

Energy  consumption:

20-30kg  firewood  or  15kg  liquid  gas  . This  type  will  save  30%  payment

  Final  product

For  the  wood,   its  calorific  value  is  6000-6500kal  for  wood  briquette  calorific  value  is  6500-7500kal.   For  the  nutshell,   the  calorific  value  is  7000-8000kal.
