Pvc Gypsum Ceiling Board

Specifications

PVC gypsum ceiling board

 1  Material : Germany KNAUF paper-faced gypsum board ,surface is imported or domestic PVC film,

Back is aluminum Foil

It’s Made of high quality paper-faced gypsum board with a layer of pvc on surface and aluminum foil on back. (Gypsum, PVC and aluminum foil are all 100% environmental friendly materials with character of water proof and fire proof.)

 2  pvc gypsum ceiling board/gypsum ceiling board's size Available Models and Specification

a> Size: (mm) 595x595 mm   595x1195 mm   600x600 mm   600x1200 mm

603x603 mm   603x1212 mm   605x605 mm   605x1210 mm

b>Thickness: (mm) 7.0  7.5  8.0  8.5  9.0  9.5  10.0  10.5  11.0  11.5  12.0

c> Designs: all kinds of designs available (Tell the pattern No.)

d> Weight:          7.5mm=5.9kg/sqm,8mm=6.3kg/sqm, 9mm=6.8kg/sqm,12mm=9.45kg/sqm

f)Quantity/20ft:   7.5mm=3800sqm,8mm=3600sqm,9mm=3200sqm ,12mm=2000sqm

g> Packing:8pcs or 10pcs in one carton, shrink plastic package

 3     Certification

. non-flammable B1, in accordance with Chinese standard
GB8624-1997

 4   advantage of the pvc gypsum ceiling board/gypsum ceiling board:

a).Environment protection product: Adopting natural gypsum material without any harmful material.

b).Non-flammable B1, in accordance with Chinese standard GB8624-1997

c).Heat retaining power

d).Sound insulating: effectively solve sound insulation and fire proof.

e).Not deforming, not cracking: keeping integrity and sound insulation for long under normal changes of.

f).Small expansion: Little coefficient of expansion, deforming under normal temperature.

g).Light weight, convenient to transport.

h).Special breathing performance, comfortable to live in.

I).Sunken proof. .non-dust, Easy clean. .good light reflection. Corrosion
