Home > Products > farm implements > Customized Mini Hydraulic Crane
Customized Mini Hydraulic Crane
- qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Application | floor | |
| Rated Loading Capacity | 1000kg | Max. Lifting Load | 1000kg | |
| Max. Lifting Height | 2150mm | Span | crane | |
| Place of Origin | Shandong, China | Brand Name | shenzong | |
| Model Number | 7D-1 | Certification | ISO9001 |
Product Description
Specifications
Specification1.Hydaulic track mounted crane 1tons
2. Provid by China manufacture factory
3. OEM and ODM are welcome
Customized Mini Crane
1.Product Show
2. Product Specification
Model | 7D-1 | |
Specification | 3.0T×1.3m | |
Max operation radius | 3.3m | |
Max Raising height | 4.2m | |
Winding | Hook up speed | 2.5m/min (4 times) |
The diameter and length of wire rope | 8mm×50m | |
Telescopic | Jib form | 5 parts (Full-automatic) |
Jib Length | 9 m | |
Up and down | Jib angle | 0-75° |
Rotary | Rotation angle | 360-degree continuous rotation |
Outrigger | The form of outrigger | First part automatic regulation,Second part manual regulation |
Maximum extend range | 2.3m×3.4m | |
Walking device | Walking style | Mechanical(3 drive 1 revert) |
Walking speed | 1.4Km/h | |
Crawler | synthetic rubber | |
Grade ability | 20° | |
Ground pressure | 37Kpa | |
Hydraulic oil tank volume | 26L | |
Dimension(L.W.H) | 2850x760x1450(mm) | |
Machine Weight | 400Kg | |
Gasoline Engine | Model | GX390(HONDA) |
Engine maximum output power | 13HP | |
Ignition system | Transistor ignition magnets(Non contacting) | |
3.Company Other Products
4.Company Information
Established in 1984, Gaomi Shenzong Agricultural Equipment Co., Ltd. is located in Gaomi, Weifang City.
Near to Qingdao Port and Qingdao International Airport. We enjoy advantageously geographical location
and convenient. After about 20 years' development, our company has become a largescale private enterprise, integrating the design, manufacture, export, casting and the mechanical products’
product to oneself. Our company has passed the evaluation of ISO9001 certification in 2008 and obtained
independent import and export rights in 2012.
Our products include car trailer, farm trailer, camper trailer, platform trailer, disc ploughs, disc harrows and
other agriculture implements. We use the most advanced technology .Our products comply with international
standards. Shenzong brand trailers sell well in more than 20 provinces, cities and municipalities of China.
Now our tractors have been exported to more than 50 countries and regions, such as the USA, Canada, Chile,
Argentina, Australia, New Zealand, South Africa, Norway, the Netherlands, Albania, Pakistan, Malaysia and ect.
Superior manufacture technique, wonderful product line and perfect service system obtain the international
ratification around the world.
Comprehensive management system, perfect quality control system, respond quickly and good service, our
company become parter of foton, maschio, shifeng, shantuo, yituo, tiantuo and other tractor brand, to design,
research and produce the farm machinery.
Our factory enjoys consumer's trust on high-quality products and perfect services.
If you are interested in any of our products or would like to discuss a customized order, please feel free to contact us.
We hope to establish strong business relationships with friends from all over the world.
4.Company Certificate
5.The Plant
6.Contact Us
Contact Us
- Shandong Shenzong Machinery Co., Ltd.
- Contact nameAlan Fu Chat Now
- Phone86-536-2353735
- AddressXujiali West,Mishui Street, Weifang, Shandong
