Home > Products > Zinc Metallurgy Equipment > Zn ore electro-winning Electrolytic Cell
Zn ore electro-winning Electrolytic Cell
- Shenzhen
- T/T Credit Card
You May Like
-
China Manufacturer High Recovery Hot galvanizing Zn residue recovery vacuum distillation furnace
-
Hot galvanizing Zn residue recovery vacuum distillation furnace
-
China Full Automatic Zinc Ingot Casting Equipment
-
High Efficiency Zinc Melting Heat Holding Power frequency cored induction furnace
-
China Zinc Melting Heating Cored Induction Furnace
-
China Manufacturer Zinc Metal and Alloy Melting Coreless Mains Frequency Induction Furnace
Product Details
| Place of Origin | Hunan, China | Brand Name | unionsum | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Zn ore electro-winning Electrolytic Cell
Unionsum provides tailor-made, environmentally sound and optimized solutions for Zinc electro-refining / electro-winning plants. Crane positioning pin, acid mist pipelines, and anode mortise are embedded with cells.
1. Lifetime And Operating Cost
Under normal working operation, the lifetime of the cell body is equal or greater than 20 years. There is not parking lost and maintenance cost unless the man-made or an accident. The operating cost is almost zero.
2. Warranty Period
We supplies goods with a warranty period of 18 months from delivery to customer or 12 months from the equipment on site installation and commissioning. In the warranty period, if the equipment or the parts emerge quality problems for our reasons, we offer repairing or exchanging service for free, and the warranty will be extended for another 12 months.
3. Technical parameters
Performance parameters | Index |
Compressive strength | 130.5MPa |
Bending strength | 23.55MPa |
Flexural Modulus | 3.36×104MPa |
Density | 2.25×103Kg/m3 |
Thermal conductivity | 6.63KJ/(m•h•k) |
Specific heat | 0.741 KJ/(Kg•°c)(20.1°c—30.5°c) 0.800 KJ/(Kg•°c)(30.5°c—40.8°c) 0.890 KJ/(Kg•°c)(40.8°c—50.7°c) |
Coefficient of thermal expansion | 16×10-6/K |
Mass resistivity | 3.56×1012Ω•cm |
Sheet resistivity | 5.95×1011Ω |
4. Application
we can provide electrolyte cell with length over 13m.
Prospecting Mining Metallurgy Processing Trading EPC service
Unionsum, a subsidiary of CRIMM, provides sustainable system solution for mining and
metallurgy industry, including engineering, procurement and construction, and offers a widerange of
scientific research and consultingservices.
Clients Visiting
Global Market
Vacuum distillation project at Bulgaria Rotary Furnace at Thailand
Contact information
Skype: claire.zhou
M.P: 86-18890384660
Web: http://unionsum.en.china.cn
Add: 3F, Yubang Internation Plaza, No.222, Xinyao Road (S),
Tianxin District,Changsha, Hunan, China
