Cold Roll Forming Machine Roof Forming Machine Cheap Price

Cold Roll Forming Machine

Parameter:
1.Suitable to process:Colored Steel plate, galvanized board
2.Width of the plate:1000mm
3.Rollers:12-13rows
4.Rolling material: Forging Steel 45#
5.Rolling galvanization thickness:0.05 mm
6.Material of the cutting blade :Cr12
7.Hydraulic oil :40#
8.Dimensions:6.7*1.35*1.51m
9.Power:3+3kw
10.Thickness of the plate:0.3-0.6mm
11.Productivity:8-10m/min
12.Diameter of the roller:70mm
13.Weight:About 3.8 T
14.Voltage:380V  50Hz
15.Processing precision : within 1.00mm
16.Equipment components: Man-made uncoiler, Roll forming machine, compture control system, hydraulic control system, cutting
17.Transportation:one complate equipment need one 40feet container to hold
18.Delivery Time:30%deposit,and balance before delivery
19.Standard components: Chain 1 pcs, Hydraulic oil pipes: 2 pcs, electromagnetism valves 1 pcs. limit switch:2 pcs
20.This machine is compose of feeding table,forming machine,forming cutting device, hydraulic system,computer control           system,discharge table.
   Optional devices have manual uncoiler,hydraulic uncoiler,aoto stacker and so on.(Optional)
21.Our products are widely used in various industral factory,civilian building,warehouse and easy steel building manufacturing,and have features such as nice apparance and durable.
