New Mobile Truck Cranes XCMG QY16K
US$ 10,000 - 300,000
/ Unit
1 Unit(Min. Order)
- China Port
- T/T
You May Like
Product Details
| Condition | New | Application | all | |
| Rated Loading Capacity | 21540kg | Rated Lifting Moment | Base boom:711.48KN.m | |
| Max. Lifting Load | 16T | Max. Lifting Height | Fully extended boomv and Jib : more 32.3m | |
| Span | Lateral: 5.4m | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG | Model Number | QY16K |
Product Description
Specifications
Truck Cranes:One stop service
Competitive prices
Comprehensive after-sale services and spare parts
Truck Crane: |
By the upgrade of lifting arm technology optimization, Xuzhou Heavy Machinery establishes the leading position in the key technologies of oblong section lifting arm and flexible lifting arm system automatically controlled by single cylinder mutually locked...... |
| Classificatory | Item | Unit | Parameter | |||
| Outline dimension | Overall length | mm | 11810 | |||
| Overall width | mm | ≤2500 | ||||
| Overall height | mm | 3170 | ||||
| Wheel base | Axle 1, Axle 2 | mm | 4025 | |||
| Axle 2, Axle 3 | mm | 1350 | ||||
| Track | Front wheel | mm | 2079 | |||
| Rear wheel | mm | 1834 | ||||
| Mass | Total mass in travel state | kg | 21540 | |||
| Axle load | Axle 1 | kg | 6300 | |||
| Axle 2 | kg | 15100 | ||||
| Travel performance | Travel speed | Max. travel speed | km/h | ≥69 | ||
| Min. stable travel speed | km/h | ≤2.8 | ||||
| Turning diameter | Min. turning diameter | m | ≤21 | |||
| Min. turning diameter at boom tip | m | ≤24 | ||||
| Min. ground clearance | mm | ≥260 | ||||
| Approach angle | (°) | ≥16 | ||||
| Departure angle | (°) | ≥14 | ||||
| Braking distance (at 30km/h with full load) | m | 10 | ||||
| Max. grade-ability | % | ≥32 | ||||
| Fuel consumption for 100km | L | 30 | ||||
| Main Technical Data for Lifting Operation | ||||||
| Classificatory | Item | Unit | Parameter | |||
| Lifting performance | Max. total rated lifting capacity | t | 16 | |||
| Min. rated working radius | m | 3 | ||||
| Turning radius at turntable tail | m | ≤2.765 | ||||
| Max. load moment | Base boom | kN.m | 711.48 | |||
| Fully extended boom | kN.m | 449.8 | ||||
| Fully extended boom + Jib | kN.m | 327.7 | ||||
| Outrigger span | Longitudinal | m | 4.68 | |||
| Lateral | m | 5.4 | ||||
| Lifting height | Base boom | m | ≥10.17 | |||
| Fully extended boom | m | ≥24.7 | ||||
| Fully extended boom + Jib | m | ≥32.3 | ||||
| Boom length | Base boom | m | 10 | |||
| Fully extended boom | m | 24.2 | ||||
| Fully extended boom + Jib | m | 32.35 | ||||
| Working speed | Boom raising time | s | ≤50 | |||
| Boom full extension time | s | ≤73 | ||||
| Max. swing speed | r/min | ≥2.1 | ||||
| Hoist speed | Main winch | Full load | m/min | ≤82 | ||
| No load | m/min | ≤100 | ||||
