Silent Gas generator set!Natural gas generator 24-500KW

Welcome to the showroom of Camda New Energy EquipmentCo.,Ltd

(http://cncamda.en.china.cn) We are professional and dedicated system supplier of energy production by diesel and gas powered generator set, waste treatment projects and solar energy. The company, based in Dongguan of Southern China, is basically a manufacturer of generator set for various kinds of fuel such as diesel, natural gas, biogas, coal bed methane (CBM), associated gas and syngas.

Genset working condition:

l Acceptable working conditions:

Ambient temperature : -10°C~+40°C

(antifreeze or preheater needed for below 0°C)

Relative humidity:<90%(20°C)

Altitude:≤1000m

Normal working conditions:

Genset can run at rated power on the conditions:

       Atmospheric Pressure: 100kPa, Ambient Temp: 20°C, Relative Humidity: 30%.

l Applied gas:

Natural Gas, Biogas, LPG, Landfill gas, Oil gas, Syngas, Coal mine gas

Acceptable fuel gas pressure: 5~12kPa

CH4 content: for natural gas≥85% CH4 content:for biogas≥55%

Gas heat value≥5500kcal/Nm3 (23MJ/Nm3 ). Genset output power will increase as the gas heat value increase, if use low heat value gas for fuel (Heat value<5500kcal/Nm3, it will lower the power efficiency.

Gas doesn’t include free water or free materials (the size of impurities should be less than 5μm.)

H2S content≤200mg/Nm3

NH3 content≤20mg/Nm3

Impurities content≤30mg/Nm3;size≤5μm

Water content≤40g/Nm3, no free water.

Standard Scope of Supply:

1. Brand new gas engine, 90% parts include engine body , crank shaft, cam shaft, piston, cylinder head, etc made by Cummins with best quality

2. Brand new brushless France Leroy Somer alternator

3. Rating: 3 phases 4 lines. 400/230V, 50 HZ , 1500rpm, 0.8PF, IP22-23, Insulation class H

4. Radiator for 40°C/50°C ambient temperature

5. Ignition system adopted USA ALTRONIC

6. Emergency stop mounted

7. Battery,Battery cable and Battery charger

8. Standard tool box

9. Standard Accessory for installation (include bellows,silencer,flange,asbestos pad,Anti-rust water,screw )

10. Gas Train include Regulator valve,Electromagnetic Valve, Fire arrestor,Ball Valve (Chinese brand)

Accessories list

1. Maintenance Operation manual

2. Quality certificate, Gen-sets ex-factory testing report

Optional:

1. Sound-proof canopy

2. CHP system

3. Grid parallel system

4. Remote radiator

5. Auto oil filling system

6. Water heater

7. Oil heater

8. Gas leaking detector

9. Flame detector

10. Gas scrubber

As the OEM and sales agent for Cummins, Perkins and Daewoo, Camda cooperates with these world famous brand to provide clients with reliable after-sell services:

1.Our factory is equipped with exquisite test platform and maintenance center. We have the completed spare parts warehouse, clients can get all the parts from our factory directly.

2.Our factory has a whole day maintenance team with strict training and rich experience. This team responses to the installation and maintenance within 24 hours.

3.Our factory will have two free training every year. Moreover, we will provide customers with technical support to update technology. .

4.After warranty period, any equipment maintenance and spare parts replacement will be charged with lowest price.

5.Our factory guarantee that we will come up with professional solution for all of your power issues.

6.All of our models are approved by ISO9001,ISO14001,OHSAS18001,CE,TUL and our factory has been verified by SGS,BV,TUV.

Advantages:

1. For our air intake system, we equip with manual ball valve, solenoid gas valve, fire arrestor and zero pressure valve. This air intake system is completed, we import the zero pressure valve directly from German which confirms the stabilization and safety of the engine.

2. For our ignition system, we use the world famous ALTRONIC system, it contains the Hall sensor,ignition module, ignition coils, high voltage wires.

The ignition time is accurate and ignition energy is high. This ALTRONIC ignition system extends the service life of the spark plug, so that the startup

performance of the unit is excellent, greatly reducing the knock probability, to improve

the stability of operation of the engine.





3. For our cooling system, according to customers' real situation, we provide several              choices: Heat Exchanger, Vertical  Water Tank and Remote Radiator



For heat exchanger, the advantages are high heat transfer efficiency, little heat loss , compact structure, small size,easy  installation and cleaning , widely used and long life.

Under the same pressure loss, its heat transfer coefficient is3-5 times higher than the tube, but its size is just one-third, its heat recovery efficiency can reach 90%.





For remote radiator, it is not easy to be clogged, good heat dissipation.
