8Ton Bauxite Ore Crusher With 45 Ton Capacity(13673361755)

Hammer Crusher

Hammer crusher is applied directly to the maximum size for the 600-1800 mm material broken to 25 or 25 mm below a crushing crusher. Hammer type crusher applied in cement, chemicals, power, metallurgical and other industrial sectors crushing medium hard materials, such as limestone, slag, coke, coal and other materials in the broken, fine works.

Hammer type crusher classification

Hammer type crusher is divided into: Single Phase Hammer Crusher, High Efficiency Crusher, Sanding Machine, Vertical Shaft Hammer Crusher, Reversible Type Hammer Crusher.

Single Phase Hammer Crusher

Single Phase Type hammer crusher, also called composite hammer crusher, mainly used in limestone crushing, large single Phase broken can be 1 meters in diameter in limestone directly broken to about 20mm, has strong crushing capacity. This type with a large number of application in cement industry.

High Efficiency crusher

High Efficiency crusher is mainly used for material fine crushing field operations, is the important equipment options. PX high-efficiency fine crusher hammer as an example, for a split structure, the hammer head and the handle are connected by bolt. Head materials with high wear resistance of Cr Mo alloy hammer, wear-resisting performance is all broken hammer of the most enduring. Hammerhead split structure, so that the replacement is very convenient hammer.

SandingMachine

This Type of machine is the most traditional hammer type crusher, hammer directly through the rod connected to the rotor. In order to avoid the breaking hammer, hammer material hardness is not too high. Therefore, sanding machine hammerhead wear-resistant cycle high efficiency hammer crusher short.

Vertical shaft hammer crusher

The biggest advantage is no plate structure, no blocking phenomenon. But the vertical shaft hammer breaking hammer and the liner plate without the formation of large angle counter process, thus crushing effect slightly lower. The hammer is an integral structure, so the repair and maintenance of complex.

Reversible hammer crusher

Mainly used in soft materials and low abrasive material fine operation. The rotor has a positive, two directions of movement skills, which can greatly improve the hammer use cycle, reduces the number of replacement hammer.
