Home > Products > gasifier furnace > 100kw Biomass Gasifier for Dryer , Boiler , Industry Furnace

100kw Biomass Gasifier for Dryer , Boiler , Industry Furnace

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

You May Like

Product Details

Condition	New		Place of Origin	Henan, China
Brand Name	Haiqi		Model Number	HQ-360
Usage	Other, SYNGAS		Production Rate	100KW
Voltage	380V 420V 440V 400V		Power(W)	100KW
Weight	30T		Dimension(LWH)	15M6M8M
Certification	CE BV SGS		Warranty	ONE YEAR
After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

Biomass gasification use wood , crop waste as fuel ,
Draft-down fixed bed type,
PLC control Panel
One worker on duty

Company Information

a. our company was established in 1997, has 9-year experience in biomass machinery field;

b. our productions including biomass pyrolysis multifunction burner, biomass gasification power plant and gas supply

system;

c. build broad cooperation relationship with 6 colleges, universities and many scientific research institutions;

d. have applied the national patent and gained many authentication and certifications;

Product Description

Our productions are suitable for wood chips, straw, sawdust, rice husk, waste wood,and other agricultural straw and

have many features and advantages.

Technical advantage: Use draft-down fixed bed type, low temperature anaerobic pyrolysis, syngas includes lower tar, gas output stable, use PLC

control system, one worker on duty, safety and stable.

Energy-saving advantage: energy saving 80% comparing with natural gas and oil. 1kg raw material produce 2-2.5m³ syngas, 2-2.5m³ produce 1KW

Environmental advantage: trace SO2 , CO2 emission ,lower than national environmental standard, ash<1.5%, flue

gas emission<50mg/m³

a. scientific design, technology advanced

b. safe for easy operation

c. save cost, save energy, protect the environment

d. the temperature can up to 800-1300°C, the length of flame can be 3-4 meter

Model

HQ-180

HQ-360

HQ-540

HQ-720

HQ-1000

HQ-1200

HQ-1800

HQ-2000

HQ-2400

Gasifier type

Downdraft Fixed bed gasifier

Dust collecting type

Dry type and wet type

Cooling type

water circulating cooling system

Ash discharge type

Hydraulic/manual

Gasify efficiency

75-80%

Gas production(Nm3/h)

180

360

540

720

1000

1200

1800

2000

2400

material

Biomass/City waste(including industry waste)

Material size(mm)

300-1000mm

0Material moisture(%)

≤18%

Main parts of system

Belt conveyor, Gasifier furnace, blender, hydraulic ash discharge system, airlock, dry type cyclone, water-bath dust collector,water-cooled air fan, cyclone for tar and water, air fan, gas burner, ID fan, cooling tower

Total power(KW)

9.25

12.6

15.7

20

24

28.5

30

35.5

47
