Automatic Weighing Sewing Biomass Pellet Packing Machine

biomass pellet packing machine description

quantitative filling packing scale machine mainly is made of automatic weighing, conveyor equipment, bag sealing equipment and computer control etc. four big parts. it has reasonable structure, beautiful appearance, smooth running, energy-saving and easy operation and acuurate weighting etc.

host uses double frequency spiral pushing, double bucket metering, advanced digital frequency conversion control technology, sample processing technology, anti-jaming technology, and realizes automatic error compensation and correction

biomass pellet packing machine functions and features

1 integrate feeding material, weighting, bag clipping, bag packing, conveying and sealing.

2 automatic pack reduction and automatic calibration during the weighing each time.

3 have functions such as long-range controlling and trouble diagnosing, repairing, ultra difference alarms and so on.

4 adopt gravity feeding method internally inside the package to ensure high metering accuracy and fast packing speed.

5 24-bit fast A/D converter and intelligent digital filtering technology, strong anti-interference, fast and stable.

the weight can be adjusted from 10kg to 50 kg, when falling down pellets to bags, it can measure weight automatically, when bags reach its adjusted weight, full bag will automatically fall down to bottom conveyor and transport to heat sealer, the sealer then automatically sealing bags and print specific time date. the pellet falling down to bags speed can be adjusted, too.

biomass pellet packing machine main structure

1 auto dosing fill system

2 auto weighting balance

3 auto belt conveyor

4 auto sewing machine or auto heat sealing machine

5 electric control cabinet

biomass pellet packing machine available materials

particle material,  granular material, pellet, rice, wheat, etc

biomass pellet packing machine model

model:  DCS-B25-Z

weighting range:  10-50kg/bag

packing speed:  6-7 bags/min

powe:  1kw

voltage:  AC 380V 3 PH 50HZ

precision:  OILMR61*(0.2)

air source pressure:  0.4-0.6Mpa

application:  particle material,  granular material

biomass pellet packing machine output product

first, we use plastic film cover the packing scale, then we use wooden case to pack machine
