Huaxing Bridge Cutting Machine for Granite and Marble
- QINGDAO
- T/T
You May Like
Product Details
| Condition | New | Type | Stone Cutting Machine | |
| Use | Granite | Production Capacity | 2000m/day | |
| Brand Name | HUAXING | Model Number | HQC40 | |
| Voltage | 380V,50HZ | Power(W) | 20kw | |
| Dimension(L*W*H) | 5700*4500*3200MM | Weight | 5000KGS | |
| Certification | commercial invoice, packing list, origin certificate | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Main technical parameter
model | HQC40C | HQC40C/A2 | HQC40D | HQC80 |
Max. disc diameter (mm) | Φ350 Φ400 Φ500 | Φ350 Φ400 Φ500Φ600 | Φ600 | Φ700,Φ800 |
max cross stroke | 3500 mm | 3500 mm | 3500 mm | 3300 mm |
max longitudinal stroke | 3200mm | 3200mm | 3200mm | 3200mm |
Max up-down stroke | 200 mm | 350 mm | 380 mm | 350 mm |
table max tilting degree | 85° | 85° | 85° | 85° |
table rotating degree | 90° | 360°(0°, 45°, 180°, 270°) | 360°(0°, 45°, 180°, 270°) | 90° |
Table size | 3250×2000mm | 3250×2000mm | 3250×2000mm | 3250×2000mm |
guide rail of side beam and main crossbeam | Straight guide rail | Straight guide rail | Straight guide rail | Straight guide rail |
Main motor power | 15KW/2 | 11KW/4 | 15KW/4 | 18.5KW/4 |
machine size | 5700*4500*3200mm | 5700*4500*3200mm | 5700*4500*3200mm | 5700*4500*3530mm |
