high quality hexagonal gabion mesh ( ISO9001 factory)

FOB Price

US$ 10 - 30 / Roll

100 Rolls(Min. Order)

Port Tianjin
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Material	Other, PVC Coated Steel Wire, low carbon steel wire, stainless steel wire
Type	Weave Wire Mesh	Application	Protecting Mesh
Weave Style	Other, Normal and reverse twisted	Wire Diameter	BWG16-27
Technique	Woven	Model Number	YTD5
Brand Name	yingtaida

Product Description

Specifications

Hexagonal wire mesh
1.Eelctro / hot galvanized or PVC coated
2.Normal and reverse twisted
3.diameter:1.8-4.0mm
4.ISO9001

hexagonal gabion mesh

Product Description

hexagonal wire mesh
Material: low carbon steel wire, stainless steel wire, aluminum wire
Weaving: Straight twist, reverse twist, double-direction twist
Coated tech: Weaving before galvanized, weaving after galvanized
Surface treated: Electric galvanized, hot dipped,plastic-coated,stainless steel, PVC coated, etc
Characteristics: corrosion-resisting and oxidation-resisting.

specifications of hexagonal wire mesh :

Specification in Metric Unit	Specification in Metric Inch	Wire Diameter in BWG	Technical Note
1.5cm	1/2’’	22	Max. Roll width 2M, single or double edge
		24
2cm	3/4’’	20	Max. Roll width 2M, single ; double edge or reinforced
		22
		24
1.8cm	5/8’’	21	Max. Roll width 4’, single or double edge
		23
		25
2.5cm	1’’	19	Max. Roll width 2M, straight or reverse twist
		21
		23
3.0cm	1.25’’	19	Max. Roll width 2M, straight or reverse twist
		21
4.0cm	1.5’’	18	Max. Roll width 2M,
		20
		22
5.0cm	2’’	18	Max. Roll width 2M,

Galvanized hexagonal wire netting
mesh			Min. Gal.v. G/SQ.M	Width	Wire Gauge (Diameter) BWG
Inch	mm	Tolerance(mm)	Min. Gal.v. G/SQ.M	Width	Wire Gauge (Diameter) BWG
3/8"	10mm	±1.0	0.7mm - 145	2' - 1M	27, 26, 25, 24, 23
1/2"	13mm	±1.5	0.7mm - 95	2' - 2M	25, 24, 23, 22, 21
5/8"	16mm	±2.0	0.7mm - 70	2' - 2M	27, 26, 25, 24, 23, 22
3/4"	20mm	±3.0	0.7mm - 55	2' - 2M	25, 24, 23, 22, 21, 20, 19
1"	25mm	±3.0	0.9mm - 55	1' - 2M	25, 24, 23, 22, 21, 20, 19, 18
1-1/4"	31mm	±4.0	0.9mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
1-1/2"	40mm	±5.0	1.0mm - 45	1' - 2M	23, 22, 21, 20, 19, 18
2"	50mm	±6.0	1.2mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
2-1/2"	65mm	±7.0	1.0mm - 30	1' - 2M	21, 20, 19, 18
3"	75mm	±8.0	1.4mm - 30	2' - 2M	20, 19, 18, 17
4"	100mm	±8.0	1.6mm - 30	2' - 2M	19, 18, 17, 16

pictures of hexagonal wire mesh :
