Layer chicken feeder

Layer chicken feeder

Technical

1.Volume of 120 liters, V-concentric hopper;

2. Reel diameter 360MM, 16 divide tank, made of pure plastic;

3. Hot dip galvanized tube,diameter 45MM,3-4 holes;

4. Driven reducer 750W, 380V, capacity 450 kg / h;

5. Hoisted 350 type two-way lifting winch;

6. Special dragon with imported high-carbon manganese steel screw material;

7. Automatic power distribution system, level electronic, mechanical control;

8. Feed pan are easy to clean, when remove the dial,it can be used on the brood food chain to open automatic feeding system.

Special advantage

1.With a 90 degree corner,the corner is made from special heat-treated material,block chain slideway are shaped by specialsteel molding,the special surface is more wear-resistant.

2.Trough and chain:chain are imported famous brand and the trough are shaped by high quality galvanized sheet,the diet restriction grid made of wire mold spotting,Pitch accuracy,when feeding it can effectively separate the cock and hen.

3.Trough,Feed box has feed position adjusting device, can adjust the feeding height according to the chicken growing.The feed hopper with a clearance which can remove the impurities in the feed

4. Drive system,with a speed 36m/min, the scientific design of gear rotation, no need add oil or other maintenance, also with automatic feed control, you can set the time and frequency of feeding.Simple structure, can be put anywhere in the customer needs.This quick automatic feeding system using advanced foreign technology, feeding faster, stable and reliable, uniform feeding, for 24 hours automatic control of feeding time.
