Chinese steel structure building prefab chicken house poultry farm

                     China steel structure building prefab chicken house poultry farm

                                                                          (brand: U-Best)

We are professional manufacturer and supplier for prefab house chicken farming equipment in

China, what could we provide for you?

1. Chicken house design--provide the best guide and service for your chicken house.

2. Layout drawing--provide layout of our equipments, you will know how to install our equipment.

3. Equipment installation--we can send our engineers to your location for on-site installment guidance.

4. Workers training--we can train your workes to ensure no-risk breeding.

5. After-sale service--prompt reply for any questions from our clients.

♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥

To give you a reliable price, please let us know:

1. Farm Size(Length x Width x Height).

2. Quantity of birds in one farm.

3. Weight of chicken when sell in market.

4. Types of chicken: broiler chicken/layer chicken/breeder chicken.

5. Types of breeding: on the ground or in cages.

6. Chicken farm location and local climate condition(temperature, humidity...)

♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥♥

1. Main feed line system:

1).The function of deliver system is to transmit the feed outside shed to the hopper of feeding system inside, control

system indicates delivery system to work automatically.

2).Feed of poultry raising farm is stored in the silo, so as to save large amount of package, and also to ensure the health

of feed. Different specifications of silos are alternative to choose according to the daily consumption and the size of silo.

Material of silo consist of galvanized sheet and glass fiber reinforced plastic.

3).If you don't use silo, you can use manpower hopper.Usually, if you just build one or two farm,we suggest you to use

hopper instead of silo.

4).This main feed line system including:

a. silo or manpower hopper;

b. driving motor(power-0.75kw/1.1kw for your option, voltage-380v/220v, three-phase/single-phase);

c. feed conveying pipe(diameter-75mm, material-PVC;

d. auger(imported from South Africa, maximum feeding capacity-1400Kg/h);

e. sensor(imported from Germany).

2. Automatic pan feeding system.

1).There is a feed sensor at the end of each feeding line which controls motor on and off to achieve feed delivery

automatically.

2).Feed pan is the core of feeding system. The feed sensor is usually installed at one feed pan of the feeding line.

The motor will start working and delivery feed when the feed sensor doesn't touch feed, the motor will stop

working when sensor touchs feed.

3)This automatic pan feeding system mainly including:

a. driving motor(power-0.75kw/1.1kw/1.5kw for your option, voltage-380v/220v, three-phase/single-phase);

b. v-shape bin(with hopper);

c. feed delivery pipe with feed pans(diameter-45mm, material-hot-galvanized steel pipe,feeding line specification

-4 feed pans/3m or 3 feed pans/3m);

d. auger(imported from South Africa, feeding capacity-400kg/h);

e. sensor(imported from Germany);

f. suspension&lifting system;

e. anti-perching system.

3. Automatic nipple drinking system.

The system provides flesh and clean water for birds,which is very vital to let the birds have a good growing

performance. Meanwhile, nipple drinking system can make the poultry house environment better. The system

has been become the necessary equipment for stander poultry feeding.

This automatic nipple drinking system including:

a. waterline front system(pressure regulating valve, filter, water meter, doser);

b. water pipe with nipple drinkers and drip cups;

c. suspension&lifting system;

e. electric shock system.

4. Ventilation system.

1).The system controls climate condition, can provide fresh air, proper humidity and temperature for birds,

ensuring your chickens provide maximum production.

2).This system including ventilation fan(box fan or butterfly cone fan) and air inlets.

3).If your chicken house is open, there is no need to use 36'' fan and air inlets, however, you might need

curtain system.

Box fan parameters:

5. Cooling pad system.

When the air goes through the pad, the heat will be taken down by the evaporation of water, so the air will

be cooled before going into the shed.

Cooling pad parameters:

Thickness:100mm;150mm

Width:300mm;600mm

Height(with frame):1660mm;1960mm;2160mm

Frame:Galvanized sheedt and Aluminium alloy

Aluminium alloy frame:High strength, good corrsion resistance, water distribution uniformity,beautiful and

practical.(we also have galvanized sheet frame)

6. Environment control system.

This system saves the labor and the resources under the condition of assuring the optimum growth environment

of the chickens. It is imported from Israel can set an optimum working mode according to the local climate and

raising environment.

7. Fogging system.

The system is multifunctional, it can achieve the aim of cooling, humidifying, disinfecting and dedusting.

8. Heating system.

Proper temperature is critical to chickens, especially day-old chicks, we have different kinds heaters, they fire

coal, diesel, gas even electricity, 4 kinds for your option.

We will ship your cargoes out within 15 days after receipt of your deposit.
