Jl Automatic Poultry Feeding System

Product description:

Meat chicken disk type automatic feeding system consists of a driving device, a hopper, a conveying pipe, an auger, trays, a suspension lifting device, an anti-perching device and a feed sensor. The main function of the system is to convey the feed in the hopper into each tray to ensure the eating of the meat chickens and automatically control the conveying opening/closing of the motor by the material level sensor to achieve the aim of automatic feeding.

Performance parameters of feeding line system:

High-quality special driving reduction motor.

Power: 0.75kw.

Voltage: 380V .

Frequency: 50Hz.

Phase: three-phase

V-shaped bin ( with hopper).

Bin volume: 115L, hopper volume: 38L

Material: Hot-DIP galvanized sheet

Feeding system

Diameter of conveying pip: Φ 45mm

Material: Hot-DIP galvanized steel pipe with the zinc coating amount of more than 275 G/M2

Helical spring auger from South Africa, feeding capacity: 450kg/h.

Material level sensor from Germany: Time delay range 0 to 2 hours.

We also can provide you with overvalue services:

Poultry house site selection

Poultry house design and construction preparation guidance.

Breeding equipment installation Breeding worker training

Breeding technology guidance

After-sale service

We can design the good project as your shed size and chicken quantity.
