Chicken farm feeders
Feeder hopper for 3 tiers to 6 tiers
Service for 5000 birds one time
Save much labor

Chicken farm feeders

Chicken farm feeders- Factory corner

Cage mesh stock	Non-stop production to keep the factory owns enough stock to make sure fast delivery time
Workshop	Full production line: wire drawing machine, welding machine, bending machine, punching machine, cutting machine
Cage wire mesh welding	Regular common cage mesh panel is made by automatic welding machines, irregular cage mesh panel is made irregular by manual welding
Chicken house design drawing	Please supply your poultry house size or your chicken raising quantity. Our designer will supply you the suitable, economical and efficient design

Item	Specification
Source type	AC, 3-Phase
Rated power	0.75KW-0.11KW
Rated voltage	220V/380V
Outline size	L by W by H=(2.3-2.7) by (1.2-1.5) by (2.0-2.25)
Hopper size	L by W by H= 0.66m by 0.256m by 0.5m
Working average rate of the hopper	Around 15g/m
Feed capacity of each hopper	35KGS-100KGS/Piece
Working speed	10-15 Meters/Min
Structure weight	550KG
Supporting orbits	Thickness=3.0mm Diam=50mm
Orbits material	Hot deep galvanized pipe
Transverse auger conveying feeding equipment	Diameter=75mm to 150mm
Connected with the silo	5000KGS TO 15000KGS

Chicken farm feeders- cage size

Type	L1	L2	L3
Size per unit(LWH) (M)	1.9 by 1.8 by 1.6	2.0 by 1.8 by 1.62	2.2 by 2.4 by 1.65
Size per cell (CM)	47by 32 by 37	40 by 38 by 38	43 by 40 by 40
Set capacity	96 birds	120 birds	120 birds
Cell capacity	4 birds per cell	4 birds per cell	4 birds per cell
Door	4 doors	5 doors	5 doors
Surface treatment	Cold galvanized	Cold galvanized	Hot deep galvanized
Lifespan	8 years	12 years	More than 20 years
Raise period	16 weeks to 72 weeks
Accessories	Cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic

Type	L4	L5	L6
Size per unit(LWH) (M)	2.0 by 2.4 by 1.77	2.0 by 3.0 by 1.95	2.2 by 3.0 by 1.95
Size per cell (CM)	47by 32 by 37	40 by 38 by 38	43 by 40 by 40
Set capacity	160 birds	160 birds	160 birds
Cell capacity	4 birds per cell	4 birds per cell	4 birds per cell
Door	5 doors	5 doors	5 doors
Surface treatment	Cold galvanized	Cold galvanized hot deep galvanized	Hot deep galvanized Cold galvanized
Lifespan	8 years	8-30 years	8-30 years
Raise period	16 weeks to 72 weeks
Accessories	Cage, cage frame, water pipe, drinkers, feeders, other necessary fittings Drinking system is automatic

Chicken farm feeders- container loading

Chicken farm feeders- Other feeding system

Trolley feeding

Feed mill

Chicken farm feeders- customers meeting
