Product Details
| Max Payload | 2600kg | Size | 6325*2280*2590mm | |
| Place of Origin | Shandong, China | Brand Name | ADM | |
| Model Number | 3HAL-D |
Product Description
HDG Popular Horse Trailer Float for 3HAL-D
Model:3HAL-D
Overall Dimensions | 6325*2280*2590mm | Chassis Size | 5475*1980mm |
Maximum Internal Dimension of Body | 5450*1930*2155mm | Color | Single or double vent or Customized |
1.TRAILER MATERIALS |
1.1CHASSIS MATERIAL double hot dip galvanized RHS(3.5mm-4.0mm) |
1.2 FRAME MATERIAL double hot dip galvanized RHS(2.5mm) |
1.3 BODY PANEL galvanized (1.2mm) |
1.4 ROOF special molded FRP 5475*1890*450mm |
1.5 NUTS & BOLTS stainless steel |
|
2.WHEELS & TYRES |
2.1 WHEEL RIM 14' aluminium alloy rims |
2.2 TYRES 185R14C |
2.3 SPARE WHEEL one |
|
3.AXLES & SUSPENSIONS |
3.1 AXLES two special trailer axles |
3.2 LEAF SPRINGS roll rocker tandem spring suspension 6 plates |
3.3 BRAKE SYSTEM 4 wheel electric brakes with break-away systems |
|
4.WINDOWS & DOORS |
4.1 FRONT WINDOW 1220*610 |
4.2 SIDE WINDOWS 3 pop-up rectangle windows,3 sliding rectangular windows |
4.3 VENTS three sash casement vent |
4.4 SIZE OF SIDE DOOR 1755*615 |
4.5 REAR UPPER DOOR 2020*1065 |
4.6 RAMP DOOR 2020*1210 |
4.7 REAR UPPER & RAMP DOOR STRUT high-intensity anti-rust strut |
4.8 HINGES FOR REAR UPPER DOOR special 6mm diameter copper hinges |
|
5.DRAWBAR |
5.1 DRAWBAR CHECKER PLATE 1.2mm aluminium |
5.2 DRAWBAR SAFETY CHAIN two |
5.3 BRACING WHEEL one |
|
6.LIGHTS & RETRO REFLECTORS |
6.1 TRAILER PLUGS square 7 wick plug |
6.2 SIDE LAMPS 6 |
6.3 REAR LAMPS LED group 6.4 REAR LAMPS STAND aluminium |
6.5 RETRO REFLECTORS 6 |
|
7.MUDGUARD |
7.1 MUDGUARD TYPE compact mudguard |
7.2 MUDGUARD CHECKER PLATE 1.2mm aluminium in the front of mudguard |
7.3 PEDAL & ALUMINIUM STEP 1.2mm aluminium decoration board |
|
8.INTERIOR & EXTERIOR |
8.1 A KITCHEN with a cupboard and all appliance from yourself |
8.2 HORSE PROTECTION FRAME full padded |
8.3 HORSE RING six |
8.4 RUBBER MATTING FOR RAMP DOOR 10mm rubber matting |
8.5 RUBBER MATTING FOR FLOOR 10mm rubber matting |
8.6 RUBBER MATTING FOR INNER SIDE PANEL 6mm rubber matting |
8.7 WOOD BOARD FOR FLOOR & RAMP DOOR 18mm hardwood plywood |
8.8 RUG RACK side |
8.9 SADDLE RACK in saddle box |
8.10 SADDLE BOX 1500mm height for 3 saddles |
8.11 PAINTING single or customized |
|
9.DIMENSIONS |
9.1 OVERALL DIMENSIONS ( L x W x H: mm ) 6325*2280*2590 |
9.2 BODY DIMENSIONS ( L x W x H: mm ) 5475*1980 *2230 |
9.3 MAXIMUM INTERNAL DEMENSION: 5450*1930*2155 |
horse float 2pcs,3pcs,4pcs horse loading style are available, the powder coating pattern can be designed and made at client's request.
for more info, pls ask us freely.
bulk fixed on the floor of container
1. we can provide OEM &ODM service
2. we can purt customer logo on the horse trailer
3. the powdering pattern can be done according to customer requirement
4. sample is availbe
5. provide high quality and competitive price
6. delivery time is quick and on time
7. pick up customer at qingdao airport or customer check-in hotel by car
Qingdao ADM Trade Co., Ltd is whole owned by Qingdao Haylite Machinery (Manufacturer) Co., Ltd's trading firm, our factory is located in the sailing city and famous port city - Qingdao, China. It covers 53,613 square meters, the workshops cover 24,371 square meters,owing CNC punching machine, CNC plate bending machine, CNC plasma cutting machine, CNC Laser cutting machine, Plate Bending Machine, Plate Clipping Machine, Pipe Bending Machines, Pipe Swaging Machines, Punching Machines and Welding Machines etc. Our factory grows continuously and has four workshops now. More than 100 workers are working for customers in our company.
The product line includes thousand of types, such as Workbench, Tent, Trailer, Fences, Chain Link Fence Fittings, Farm Fence Hardware, Livestock Equipment for Sheep, Cattle and Horses, Dog Kennels, Traffic Accessories, Scaffolding and Farm Equipment. Our products are exported through Qingdao Port which has the advantage of convenient transportation. With high quality and good service, we are well accepted by customers in the USA, Australia, Western Europe, Japan and South Africa. We welcome you to visit us and we look forward to the cooperation.

we have been attending Canton Fair, Cologne Hardware, EuroTier, International Garden and Landscape Architecture Trade Fair in Poland, National Hardware Show in Las Vegas, Fencetech Show in MiamiUSA, World Pork Expo Des Moines,Iowa USA, World Dairy Expo in USA, Sima Show etc shows in the world.
