Cooling System for Poultry House (single Black)

Place of Origin	Shandong, China		Brand Name	JIENUO
Model Number	7090/6090/5090

Specifications

Cooling pad for poultry house
1.Single black side
2.Corrosion resistance
3.Different size
4.Environmentally friendly

Available Size (5090)

Note: the Size could be made according to the customer.

H: Height    W: Width   D: Depth   h: corrugation height

α: corrugated sheet angle (1)      β: corrugated sheet angle (2)

	Pad5090
H (mm)	1500, 1800, 2000
W (mm)	600, 300
D (mm)	100, 150, 200
h (mm)	5
a (*)	45/30
β(*)	45/60

   *** Sizes of Evaporative Cooling Pad can be made by buyers’ request

Features

1. Great permeability ensures water is uniformly distributed along the length of the watted pad, contributing to higher cooling efficiency (over 85%).

2. Containing no surface active agent, the cooling pad absorbs water quickly, with a high rate of diffusion. Generally, a drop of water can be totally diffused within 4-5 seconds.

3. The water absorption rate of this product can be 60~70mm/5min or 200mm/1.5 hour.

4. The ripple paper which has undergone special treatment features high structural strength, corrosion resistance and long life.

5. Ripple paper comes with three specifications (50/90, 60/90, 70/90) for customers to choose from. It can also be customized upon request.

6. As they are clean, non-toxic, non-smelly and eco friendly, Aonuodi cooling pads are an ideal procuct for humidification, temperature reduction and air purification applications.
