Good Sales Service Innaer Factory On Supply Chicken Egg Layer Cage

material

cold-drawn low-carbon wire (Tensile strength:480MPa )

Wire mesh cage

surface treatment

electrogalvanize

1. Surface smooth,and bright,, zinc coating:20-30g/m2

2.It is easy to rust, But after the rust does not affect use, service life:8-10 years

Hot galvanized,Zinc coat

:More than500g/m2

1. surface zinc is thick, can reach about 500g/m2, don’t easy to rust ,
2. the surface have zinc knot, not smooth, service life:20-25 years

3.We suggest that the surface treatment is PVC coating at the bottom mesh of the cage,Such eggs will not be damaged because of rough surface.

Layer cage product specification

Product model

Type

Tier

Size: L*W*H

Capacity/set

Nest/set

A012

Atype

3

1.88M*2.2M*1.45M

96 birds

24 nests

A013

Atype

3

2M*2.3M*1.45M

96 birds

24 nests

120 birds

30 nests

A014

Atype

3

2.15M*2.3M*1.45M

120 birds

30 nests

A015

Atype

4

1.88M*2.5M*1.85M

128 birds

32 nests

A016

Atype

4

2M*2.5M*1.85M

128 birds

32 nests

160 birds

40 nests

A017

Atype

4

2.15M*2.5M*1.85M

160 birds

40 nests

A018

Atype

5

1.88M*2.8M*2.35M

160 birds

40 nests

A019

Atype

5

2M*2.8M*2.35M

160 birds

40 nests

200 birds

50 nests

A020

Atype

5

2.15M*2.8M*2.35M

200 birds

50 nests

If you need the H type cage, we will provide you with detailed specifications

If the customer have special requirements, Can do according to customer requirements.

Broiler cage product specification

Product model

Type

Tier

Size: L*W*H

Capacity/set

1day-40days

B09

Atype

3

1.6M*2.3M*1.5M

90-360 birds

B10

Atype

3

1.98M*2.3M*1.5M

90-360 birds

B11

Atype

3

2.1M*2.3M*1.5M

108-400 birds

B12

Atype

4

1.6*2.6M*1.5M

120-480 birds

B13

Atype

4

1.98M*2.6M*1.5M

120-480 birds

B14

Atype

4

2.1M*2.6M*1.5M

144-550 birds

If you need the H type cage, we will provide you with detailed specifications

If the customer have special requirements, Can do according to customer requirements.

baby chicken cage product specification

Product model

Type

Tier

Size: L*W*H

Capacity/set

1day-20days

Nest/set

C40

Atype

3

1.6M*2.3M*1.4M

180-360

18nests

C41

Atype

3

1.98M*2.3M*1.4M

180-360

18nests

C42

Atype

3

2.1M*2.3M*1.4M

200-360

18nests

If you need the H type cage, we will provide you with detailed specifications

If the customer have special requirements, Can do according to customer requirements.
