The electric fence energizer for perimeter security electric fence system

Specifications

The electric fence energizer for perimeter security  electric fence system

Technique specification:

1.Power supply :AC180V-240V 50Hz

2.System power consumption : 10 Watt
3.Operating environment
4.Temperature:-40 to +50°C
5.Relative humidity :≤95%
Output parameter
Output peak voltage: 5KV~10KV
Output low voltage: 700~1000V
Peak current of pulse: <10A
Pulse duration: ≤0.1s
pulse interval time: 1s
Max quantity of electricity of pulse: 2.5mC
Max energy of pulse: ≤5.0J

Feature:

1.Differential voltage output technology: every wire has voltage, have the differential voltage between the two

adjacent wires.

2.LCD or LED indicate the working state and the voltage on every wire of fence.

3.High/low voltage switch manually, long-distance equipment auto switch function.

4.Short circuit, break and tamper alarm, Self-inspection System for equipment fault
5.Waterproof casing and downward appearance design leading the industry development.
6.RS 485 bus control, keypad, computer, network and multiple long distance management solution.
7.DC12V, NC/NO dry contact alarm output, can work with other modern security products

8.Lanstar electric fence energizer forperimeter security  with CE,ISO certificate

The electric fence energizer for perimeter security  electric fence system  with high voltage pulse to intruders tonuching the fence .

Electric fence energizer  LX-2008SC

Lanstar have various of electric fence energizers

Case pictures:

What's the Install types you can choice?

Six-line installation on the top of wall

Four line installation on the top of wall

 Attached installation

Stand alone installation

Exihibition pictures:

Packing details:

Demension: 410×320×220 (mm)
Net Weight: 4.2kg
(Without battery)

Color: Blue
Packaging Details: Carton package

1.Sample order acceptable

2.Customized logo with OEM service is available for bulk order

3.Warranty:3 years(except artificial damage and  vis major)

4. Considerate service after sale

 What is electric fence system?

Electric fence system(the electric fence energizer and front fence ) is a psychological and physical barrier to detect,deter and delay intruders or wild animals with non-lethal high voltage pulse,which is widely used in farming and security areas.

Why choose us?

• Years of experience in electric fencing field
• High quality after-sales service (quality review, shipping tracking, etc.)
• Professional staffs for providing different solutions
• Provide 2 years warranty
• Provide customize service
• High Quality products and competitive prices
• Factory warranty with CE certificate and ISO9001:2008 certificate
• Sales market covering various regions in Asia, Africa,Europe, Australia and America etc.

 Please don't hesitate to contact us!

The electric fence energizer for perimeter security  electric fence system  with high voltage pulse to intruders tonuching the fence . which establishes a physical and psychological barrier to prevent invasion .
