Perimeter electric security fence energizer for residential use

Specifications

Perimeter electric security fence energizer for residential use

Perimeter electric security fence energizer for residential use, generates high voltage pulse of 4KV-7.5KV to intruders touching the fence,which establishes a physical and psychological barrier to prevent invasion,it has a "anti-cut "special detect functions by used a anti-cut module .

Features

• Shell level of protection achievedIP55;

• Remote control the Arm/Disarm;

• DC12V, NC/NO dry contact alarm output, can work with other modern security products;

• Function of query the alarm records and arm/disarm records;

• Short circuit, break and tamper alarm, Self-inspection System for equipment fault;

• LCD indicate the arming mode,alarm state,and the voltage on every wire of fence,etc. ;

• Backup battery power supply system ,the backup battery life >8H;

• Differential voltage output technology: every wire has voltage, have the differential voltage between the two adjacent wires;

• High/low voltage switch manually via software or hardware, long-distance equipment auto switch function;

• With high/low voltage, time, zone,alarm delay, Anti-cut sensitivity and other settings functions;

• RS 485 bus control, keypad, computer, network and multiple long distance management solution.

• Lanstar Anti-cut electric fence energizer for perimeter security  with CE,ISO certificate

Perimeter electric security fence energizer for residential use

Exihibition pictures:

Technique specification:

1.Power supply :AC180V-240V50Hz
2.System power consumption : 15 Watt
3.Temperature:-25 to +55°C
4.Relative humidity :≤95%
Output parameter:
Output peak voltage: 4KV~7.5KV
Output low voltage:<1.0KV

Peak current of pulse: <10A
Pulse duration: ≤0.1s
pulse interval time: 1s~1.5s

Max quantity of electricity of pulse: 2.5mC
Max energy of pulse: ≤5.0J

Packing details:

Demension: 410×320×220 (mm)
Net Weight: 4.2kg(Without battery)
Color: Gray
Packaging Details: Carton package

Our Industrial Park

Sales Department

Production Line

1.Sample order acceptable

2.Customized logo with OEM service is available for bulk order

3.Warranty:3 years(except artificial damage and  vis major)

4. Considerate service after sale

 What is electric fence system?

Electric fence system(the electric fence energizer and front fence ) is a psychological and physical barrier to detect,deter and delay intruders or wild animals with non-lethal high voltage pulse,which is widely used in farming and security areas.

Why choose us?

• Years of experience in electric fencing field
• Professional staffs for providing different solutions
• High Quality products and competitive prices
• Factory warranty with CE certificate and ISO9001:2008 certificate

Perimeter electric security fence energizer for residential use with high voltage pulse to intruders tonuching the fence . which establishes a physical and psychological barrier to prevent invasion .
