Perlite fire resistant & insolution wall/door core board

Fire door core board produced by our company using expanded perlite as the main raw material, inorganic adhesives and chemical additives mixed with a certain proportion, through a set of process as. As a result of the expanded perlite is a natural perlite ore, structure after high temperature above 1300 DEG swell and become, granular spherical body hollow honeycomb, so fire door core board made is an ideal product for natural green environmental protection.

From raw materials into the factory to the finished product, the entire manufacturing process through the production and inspection strict and meticulous, coupled with our company's special fireproof glue, steel wooden fire door core board production by domestic customers to use and after testing, fire resistance limit to the new national standard of first class fire door.

Fire door core board, fireproof glue produced by our company have passed the combustion properties of GB grade 8624-2006/A1 (NO:200710615), GB/T 20285-2006 "material smoke toxicity risk classification" AQ1 level (NO:200810831) test.

product characteristics:

1, natural environmental protection, non-toxic and non radioactive

2, fire prevention, moistureproof, corrosion resistance

3, lightweight, heat insulation, sound absorption, good heat insulation

4, beautiful appearance, economy, convenient (installation, can be attached to or embedded in the structure)

5 can be cut, plasticity of the planer saw, with higher, to meet the different needs of practical application.

Main performance:

1, density (D): 250-300kg/m3

2, the flexural strength of more than or equal to 8MPa

3, the compressive strength: 0.35-0.8 (Mpa)

4, the coefficient of thermal conductivity: less than or equal to 0.035-0.076W/ (m.k)

5, water content (%): less than 10

6, wet expansion rate (%): less than 0.25

7, refractory limit: 0.6-2h

8, fire resistant temperature of 1300 DEG C:

9, the sound absorption coefficient: 0.03-0.8

Product specifications:

900mm * 2100mm * 25mm-70mm

The useage of fireproof core board:

Perlite fireproof door core board is mainly used for the filling material of wooden fire door, steel fire door, widely suitable for families, fire insulation requirements of high hotels, office buildings, commercial shopping center, floor compartment, schools, laboratories, hospitals, railway stations, airports, theatre, dance halls, entertainment city, factories, activity rooms and other interior decoration wall, fire prevention, heat insulation, sound insulation function.
