two-stage coal gasification machine

FOB Price

USD $550,000 - $660,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Product Type	Other, machinery	Place of Origin	Jiangsu, China
Brand Name	TYJX	Model Number	TYCG
After-sales Service Provided	Engineers available to service machinery overseas

The two-stage coal gas generator is of high calorie value, good stability, big operating elasticity, high automation

Technical Parameter:

Name	Specification	TYLII-2.0	TYLII-2.5	TYLII-3.0
I.D.Of chamber	mm	2000	2500	3000
Chamber cross-section area	m³	3.14	5.31	7.07
Coal size	mm	20-40	25-50	30-60
Air consumption	m³/Kg	2.0-2.5
Steam consumption	Kg/Kg	0.3-0.5
Gas output	m³/h	2500-2800	3600-4000	5000-7000
Net heating value	KJ/m³	6060-6270	6060-6270	6060-6270
Up stage	KJ/m³	7110~7350
Down stage	KJ/m³	5225~5434
Saturated temperature	°C	50~65
Steam seal pressure of poking hole	Kpa	<294
Steam products	Kg/h	300	450	600
Coal feeding system		Compressed air or hydraulic driving
Ash try speed		2.97	1.7	1.5
Coal feeder hydraulic station power	Kw	4.0	5.5	11
Discharging ash mode		Automatic wet discharging ash
Applicable coal		Coke,Anthracite,Bituminous coal
Feeding coal mode		Automatic
