Compact Cordierite Honeycomb Monolith
- SHENZHEN SHANGHAI
You May Like
Product Details
| Place of Origin | Jiangxi, China | Type | Ceramic Rollers | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | Cordierite Honeycomb Monolith | Brand Name | KANGYU |
Product Description
Ceramic honeycomb used for RTO application
Cordierite i s a magnesium alumina silicate material, which has very low linear expansion, low coefficient of thermal expansion and excellent resistance to thermal shock. Cordierite also offers an excellent range of mechanical strength, porosity criteria, and excels in cost-effective extruded and dry-pressed forms.
Cordierite Honeycomb Monoliths are divided into two types: porous type and compact type.
Chemical composition
SiO2 | Al2O3 | MgO | Fe2O3 | Na2O | K2O+CaO |
48-50% | 37-39% | 7-9% | <1% | <1% | <2% |
Physical properties
Index | Value |
Gross density(g/cm3) | 2.22-2.45 |
Average linear expansion(20-1000°C) (10-6/k-1) | <3 |
Specific heat capacity(KJ/Kg) | 850-950 |
Temperature cycle resistance(K) | 250 |
Max operation Temp.(°C) | 1300 |
Acid resistance(%) | >98 |
Water absorption(Wt%) | <3 |
Open porosity(%) | <3 |
Heat conductivity(W/mk) | 1.5-2.5 |
Mean heat storage capacity(Kwh/m3k) | 0.252 |
Thermal efficiency
Velocity (M/min) | Thermal efficiency | Assumptions Combustion Temp. :816°C Inlet Temp. :20°C Section Area:7.5 m2 Bed height:1200 mm Cycle time:180 seconds | ||
50*50 | 33*33 | 25*25 | ||
60 | 95.4% | 92.4% | 91.2% | |
75 | 94.6% | 91.0% | 89.4% | |
90 | 93.9% | 89.6% | 87.6% | |
105 | 93.2% | 88.4% | 85.7% | |
120 | 92.6% | 87.2% | 83.8% | |
135 | 92.0% | 86.0% | 82.0% | |
Application
Used in heat storing HTAC to exchange gas and store heat
Heat storing honeycomb carrier is also called high temperature incendiary heat storing carrier. It is the key and core part of heat storing HTAC. It has been widely used to all kinds of pushing-steel heating furnace, stepping heating furnace, heat treatment furnace, forging furnace, dissolving furnace, steel wrapping/middle wrapping baking apparatus, soaking pit, radiation tap incendiary apparatus, covering furnace, high temperature hot-blast stove in metallurgical machine building and all kinds of ceramic cellar stove, glass cellar stove in building materials, and all kinds of tap heating stove, splitting stove, other industrial stove cellar, too.
