Furnace Kiln Light Refractory Bricks Insulation Bircks
- Qingdao
- T/T D/P D/A
You May Like
-
Kiln Heating Insulation Light Brick
-
Induction Furnace Thermal Insulation Bricks -- Approved GB/T10699-1998
-
Hydrogen Furnace Insulation Light Weight Insulation Brick
-
Sunshine Brand Kiln Heating Insulation Light Weight Clay Brick
-
Incineration Plant Insulation Light Weight Insulation Brick
-
Blast Furnace Insulation Light Weight Insulation Brick
Product Details
| Place of Origin | Shandong, China | Shape | Brick | |
| Material | Mullite | SiO2 Content (%) | 50% | |
| Al2O3 Content (%) | 45%(min) | MgO Content (%) | 0.4 | |
| CaO Content (%) | 0.3 | |||
| Model Number | #23 | |||
| Brand Name | Sunshine |
Product Description
Insulation Brick
Surya Thermal Insulation Material Co.,Ltd is a professional manufacturer and exporter of all kinds of insulation materials.We can supply Calcium Silicate series,Ceramic Fiber series, Light insulating brick series,Foam Glass series,Rock Wool series and other insulation materials.Our insulation products have been sold well inland and have been exported to more than twenty five countries and areas,such as Asia,Europe,Africa,etc.Our products and services have got high reputation from our customers all over the world.
Technical data:
Index/brand | 23# | 26# | 28# | 30# | 32# | |
Classification Temperature °C | 1260 | 1430 | 1540 | 1650 | 1760 | |
bulk density g/cm3 | 0.6 | 0.8 | 0.9 | 1.03 | 1.25 | |
breaking strength MPa | 0.9 | 1.5 | 1.6 | 1.7 | 2 | |
compressive strength MPa | 1.2 | 2 | 2.6 | 2.8 | 3.4 | |
Linear change rate % °CxHr | -0.1 | -0.5 | -0.8 | -0.9 | -0.9 | |
1230X24 | 1400x24 | 1510x24 | 1620x24 | 1730x24 | ||
Thermal conductivity | 400°C | 0.17 | 0.24 | 0.3 | 0.4 | 0.49 |
(W/m.k) | 600°C | 0.19 | 0.27 | 0.32 | 0.42 | 0.5 |
| 800°C | 0.22 | 0.3 | 0.35 | 0.44 | 0.51 |
| 1000°C | 0.25 | 0.32 | 0.38 | 0.45 | 0.53 |
| 1200°C |
| 0.35 | 0.39 | 0.47 | 0.55 |
Al2O3 % | 45 | 55 | 65 | 72 | 76 | |
Fe2O3 % | 0.9 | 0.8 | 0.5 | 0.4 | 0.3 | |
SiO2 % | 50 | 42 | 32 | 26 | 22 | |
TiO2 % | 1.2 | 1.3 | 0.5 | 0.5 | 0.3 | |
CaO+ MgO % | 0.7 | 0.3 | 0.2 | 0.3 | 0.2 | |
K2O+ Na2O % | 1.3 | 1 | 0.8 | 0.2 | 0.1 | |
230x114x65mm, 230x114x76mm We can also provide size as customers’requirement. | ||||||
Advantage:
1. Industrial furnace masonry regenerative losses and furnace surface heat loss, generally accounts for about 24 to 45% of the fuel consumption.With low thermal conductivity, low thermal capacity of lightweight brick for furnace construction materials, can save fuel consumption;
2. At the same time, because of kiln can be rapid heating and cooling, can improve the efficiency of production equipment;
3. Also can reduce body weight, simplify the kiln structure, improve product quality, reduce the environment temperature, improve working conditions.
USES:
1. Metallurgical industry: the blast furnace, blast furnace hot blast stove, heating furnace, etc.
2. Petrochemical industry: ethylene cracking furnace, hydrogen furnace, a furnace, furnace, etc.
3. Ceramic industry: roller kiln, push board kiln, etc.
4. Industry: glass kiln heat storage room, etc.
5. Carbon industry: carbon calciner, etc
6. Aluminum electrolytic industry: aluminum electrolytic tank, etc.
7. Other industries: tunnel kiln, shuttle kiln, etc
1.The competitive price, our price is not higher than any factory.
2. We have strict quality inspection system.
3. Professional foreign trade team to be a strong link in our communication with clients.
4.The standard and characterized packing as per every client's requirement and product's feature.
1.Are you a trader or manufacturer?
We are manufacturer,we have own factory also trade
2.Can you accept OEM or ODM?
Of course,Logo is also acceptable.
3.What is the delivery time?
About 10-20 days after order place.
4.What is your payment methods?
T/T L/C D/P Paypal West Union
5.What is your price term?
FOB CNF CIF are available
