Home > Products > 650 Degree Calcium Silicate Board > Light Weight Fire Resistant Board
Light Weight Fire Resistant Board
US$ 150 - 200
/ Cubic Meter
2 Cubic Meters(Min. Order)
- QingDao
- T/T D/P D/A
You May Like
-
Non Asbestos Calcium Silicate Insulation Board
-
Insulating Board/SiO2 43% Product Approved GB/T10699-1998
-
Protective Equipment 650C Calcium Silicate Board
-
High Quality Insulation Board Of Wall Manufacturer
-
100% Non-Asbestos Calcium Silicate Insulation Board
-
High Density Calcium Silicate Fire/Heat Insulation Board
Product Details
| Place of Origin | Shandong, China | Brand Name | laizhou sunshine | |
| Model Number | 600*300*50mm |
Product Description
Specifications
model size 600*300*50max working temp 1000C
linear shrinkage 2%(1000C 6H)
100% asbestos free
Description
CALCIUM SILICATE BOARD (650C--1000C)applicable to work environment ranging from 600 to 1000 Celsius degrees. This product family combines the advantages of light weight, low thermal conductivity and high temperature resistance with chemical resistance
Typical Application
Lining for industrial furnaces
(heating furnace, soaking, pit, annealer, metallurgy industry)
Cooling machine in cement kiln
Glass furnace
Pottery kiln
Petrochemical industry
High temperature flue in metallurgy industry
Power plants
Shipyards
Paper mills
Backing material of refractory bricks
| Product Grade | |||
| Grade | 1000 Calcium Silicate Board | 650 Calcium Silicate Board | |
| Classification Temperature | ° C | 1000 | 650 |
| Max Working Temperature | ° C | 1000 | 650 |
| Chemical Composition | |||
| Grade | 1000 Calcium Silicate Board | 650 Calcium Silicate Board | |
| CaO | % | 45 | |
| SiO2 | % | 47 | |
| Fe2O3 | % | 0.3 | |
| Al2O3 | % | 1.0 | |
| Physical Properties | |||||||
| Grade | 1000 Calcium Silicate Board | 650 Calcium Silicate Board | |||||
| Density | k g / m 3 | 170 | 220 | 300 | 170 | 220 | 300 |
| Moisture | % | 7.5 | 7.5 | ||||
| Cold Crushing Strength | Mpa | 0.5 | 0.6 | 0.7 | 0.6 | 0.7 | 0.8 |
| Modules Of Rupture | Mpa | 0.25 | 0.3 | 0.35 | 0.3 | 0.35 | 0.4 |
| Thermal Conductivity W/(m. K) Average 70 ° C | 0.055 | 0.062 | 0.07 | 0.058 | 0.062 | 0.07 | |
| Linear Shrinkage | % | 2 | 2 | ||||
| Available Size | |||
| Grade | 1000 Calcium Silicate Board | 650 Calcium Silicate Board | |
| Size | mm | 600x300x25-75 and 1000x500x25-75 | |
