JINHE Brand small capacity powder JHN 110 mixer 60-110L for sale

JHN series Powder Mixer is an excellent equipment which bears extraordinary imagination of our designers. It combine double movement mixing principle and complicate mixing task perfectly.

1st  Different volume containers can be installed whenever needed. When customer install one 3 L container, it can be used as test for mini mixing. If install one 15L container, it can finish small batch mixing task, fully develop the vast potential of the machine.

2nd  Inherited the advantage of double movement, this utility-type machine not only realize cross revolving shaft double movement, but also has its inherent advantages such as ideal mixing effect, large loading ratio, cost less time, saving electricity and money.

3rd  Convenient installation: A skillful worker only needs 5 minutes to change and install containers.

4th  Dismountable installation: containers can be used as special purpose, dismounted and cleaned whenever needed, so this machine can effectively prevent cross-contamination between batches.

JHN Series Internal Structure:

1. High quality turbine reduction gear with long life span & low noise.

2. High quality stainless steel container, convenient for dismount and installation.

3. Tapered spiral blade, revolving speed of blade is 1.5 times faster than container.

4. Machine shell surface all spray model and baking varnish disposal, beautiful-looking and endure cauterization.

Technical Parameters:

 Wooden case

9-30 working days after receive deposit

Zhengzhou Jin Tai Metal Materials Co., Ltd. was established in 2001.It is a mixer (also known as mixing machine) professional manufacturer. The corporation has about 125 staff, including 15 senior engineers, which integrates research and manufacture during its development. The company's production department is located in No.1 Zhongxing Road in Xinzheng city and headquartered in Weilai Garden,No 71 WeiLai Road Zhengzhou city ,which is close to the famous Zhengdong New District.

For mixing equipment, most companies are still producing the traditional equipment, some equipment didn't change over 30 years. Over the years Jin Tai cleaves to the spirits of” Made in China” in the field, devoting research to innovating in order to improve the efficiency and save more energy. At present we have the independent intellectual rights and national patent technology of our products .In the creation part of domestic mixing equipment , Jin Tai has been taking the lead.
‘Made in China’ has been the dream of several generations in industrial field. Being the main force of the independent innovation , Jin Tai has the responsibility to make a contribution to the development of Chinese industry ,and keep innovating and moving forward to make more products of high quality .

1. Do you have a small capacity mixer/blender of 3 liter?

    Yes, we have small capacity mixer from 3L to 110L for lab use.

2. Is it easy to clean so that we can mix/blend different powder one batch after another?

    Yes, our lab series mixer's inside blades and barrel are all dismountable. You can clean it thoroughly  by yourself.

3. Is it possible to mix/blend 3 liters or 15 liters with one machine only?

    Yes, There is 6 size barrel for 1 mixer from 3L to 18L. You can choose what you need.

4. If I want to mix different powders particle size in 200mesh(74um), how long would be ok?

    10 minutes or less upon the fluxility of the powder

5. If I want to mix powder size smaller than 800 mesh(19um), would it also capable?

    Yes

6. If I want to mix light powder and heavy powder, like Mgnesita powder and Cromo powder, the light powder is easily floating on the surface of heavy powder, then the light powder can not well- dispersed. Does your mixer can slove this problem?

   Yes, absolutely. Our double movement series mixer have unique structure over the world. The barrel rotating while the inside 8 full size helical blades rotating also. The barrel rotating like a 3D mixer. The inside helical blades can do cutting, dividing,pressing job. If our machine used to mix normal powders like milk powder,detergent powder,protein powder, etc.....it will need less time than other mixer.

7. I am in food industrial, what kind of mixer/blender is better for me?

    All parts connect to food mixture need better quality stainless steel 304/316 to prevent contaminate.

8. I am in chemical industrial, what kind of mixer/blender is better for me?

   Pls check if the chemical powder have corrosivity. If so, you need use better SS 304/316 anti-acid barrel.

9. I am in metallurgy industrial, what should I take special care of?

   If the powder is super fine, they are easily getting into a ball when mixing. Sometimes the powder would stick to the corner of the barrel and do not partake mixing, this is what we called "dead corner". It is affect mixing effect and products quality.

   1) For example, diamond tools industrial. if the raw material powder did not well-mixed, the tools would easily get split.

   2) Refractory industrial, aggregate and additive, if the powder did not well-mixed, it will reduce the service life.

   3) Food industrial, instant coffee, protein,tea dust,flour, the additives must be well-mixed, otherwise, it will affect taste or effect.

10. Why your mixer's/blender's price higher than others'?

     If you have such question, pls compare with others' mixer first.

     Does their mixer have inside blades?

     Does their blades can rotating in different direction&speed with barrel rotating?

     Does their loading rate can reach 75%?

     Does their mixer's loading weight better than us?

     After you checked everything, you will find that our price is very reasonable.
