Wing-folded Heavy-duty Hydraulic Disc Harrow Cultivator

FOB Price

US$ 5,000 - 10,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Farm Cultivator
Power Type	Other, 4WD tractor	Certification	BV ISO9001
Warranty	one year	Use	break soil
Place of Origin	Shandong, China	Brand Name	Qingquan
Model Number	TAZN/TAZM	Weight	6T
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

iron net box

Product Description

wing-folded heavy-duty hydraulic disc harrow cultivator

Product Description

Product Description:

TAZN Series Hydraulic Folding Offset Heavy Duty Disk Harrows, with super high strength harrow frames and discs, are specially used in large farm or pasture for superficial plowing, harrowing and shattering of clods, smashing and mixing crop residues or plant roots into soil as green manures, for preparation of soil before sowing. The disk harrow especially performs excellently in tougher soil condition.This series of disc harrows specially adopt hydraulic & tire mechanism to control cutting depth of harrow, and facilitate transportation during and after harrow working. Suitable for matching high power tractors.

Technique parameter:

• 42mm diameter round harrow shaft used, 290mm spacing between discs, matching 10.0/75-15.3 tires

• High Carbon disc blade hardness: 38-44 HRC, assuring the toughness and wear ability of disc blade
• Super heavy disk harrow, performing well in tough soil conditions, harrowing more thoroughly

• 140*140*10mm tubular steel harrow beams used, more durable in harrowing work

• Large and thick 28’’×8 harrow discs used, fulfilling deep tillage requirements

• Wheels linked to hydraulic cylinder, facilitating harrow maneuvers, disc depth control and harrow transportation over long distance .

Model	No. Of disc	Working width	Disc dimension	Tractor power
		mm	Inch*mm	hp
TAZN	28	3920	28*8	200-210
	32	4475		220-240
	36	5030		260-280
	40	5590		300-320
	50	7080		350-370
	54	7635		380-400
	56	7940		450-500

Company Information

---Product:Disc harrow,discplough,mouldboardplough,rotarytiller,trailer,mower,spreader,seeder ,thresher,Potato planter and harvester,rear blade,cultivator,disc blade,all kinds of farm machiner parts.

---we are the only one draft of China disc harrow and mouldboard plough standard as manufacturer unit

---we are quality supplier of domestical tractor manufactuer,like YTO,Foton Lovol

---we are the recommended unit of the farm implement project at home and abroad , we also sent our engineers to those countrys to help the assembling and using for one year around which enjoy good remarks

---158 employees and 66 engineers and technicians

--- the main market is Africa,Latin-America, Europe , South-east Asia and so on.

Our company Shandong Tiansheng Machinery Co., Ltd , a private enterprise specializing in developing, selling and producing the agricultural machinery, which is China's outstanding agricultural expert, we have self-supported import and export right.The quality of our products is reliable and the performance is well.The main products of Shandong Tiansheng Machinery Co., Ltd. include: Qingquan brand disc harrow, disc plow, mouldboard plow, rotary tiller, potato planting (harvest) machine, cultivator, subsoiler, seeder, leveler, ridger,trencher, stubble cleaner, earth auger, fertilizer distributor, farm trailer, and the other farm machinery.

The main market is Africa,Latin-America, Europe , South-east Asia and so on.

FAQ

1. Are you a trade company or a manufacturer?

We are a manufacturer who have factory of ourselves, and we have our own Foreign Trade Department for exporting since 2005.

2. Where are you located in and which port is the nearest?

We are located in Yucheng City, Shandong Province of China, about 50 minutes driving distance to Jinan City. The nearest port is Qingdao, sometimes we also export from Tianjin Port and Shanghai Port.

3. What’s your main products?

We mainly produce tractor matched implements and their spare parts. Our agricultural implements can match with wheel tractors of JOHN DEERE, NEW HOLLAND, MASSEY FERGUSON, SONALIKA, KUBOTA etc., and China’s brands like YTO, FOTON LOVOL, BOMR etc..

4. What’s your delivery time?

Normally 15-20 days if quantity less than one container, about 30 days if one container quantity.

5. Do you have the ability and accept OEM or ODM?

Yes, of course. We have experienced processing craft to undertake OEM, and we also have technical designing experts to undertake ODM.

6. How can I trust your company and products? Do you have some certificates?

We’ve been exporting agricultural implements since 2005, having many distributor and user customers in 66 different countries, who praise highly of our company’s service and product quality.

And we annually undertake China’s Aiding Projects of Agricultural Machinery directed by the Ministry of Commerce of the People's Republic of China, we winned reputation by our product quality.

We have ISO9001: 2008 Certificate, BV(Bureau Veritas) Certificate.

Our Services

Provide professional person to communicate with you and serve you whole course.

Provide strict quality check for each part, each process before export.

Provide complete technical guide after-sale services.

Provide the model you demanded according to your drawing or sample.

Providing the best products and all-aspect services are our eternal tenet.

Packaging & Shipping

1, Nude packing for disc blade and trailer;

2, Iron box packaging for small quantity or less than container load.

3, Full container load

Payment Terms

--TT,30% as the first payment and the balance before shipment.

--Irrevocable LC at sight

--DP at sight
