Shenyang Acecare Technology Co., Ltd.: Shenyang, Liaoning, China; Main products: Carbon Fiber Cylinder, Oxygen Medical Cylinder, Hydrogen Cylinder, CO2 Cylinder, Gas Cylinders

Home > Products > CNG Composite Cylinder(Type 2) > Acecare fiber composite gas cylinder,safe and reliable, composite cng cylinder

Acecare fiber composite gas cylinder,safe and reliable, composite cng cylinder

FOB Price

USD $110 - $200 / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Composite cng cylinder

Standard Technical specification

Steel cylinder hoop-wrapped with glass fiber used for vehicles (type II cylinder)

Part No.	Water Capacity	Liner Diameter	Outside Diameter	Empty Weight	Length	Working Pressure
Part No.	Water Capacity	Liner Diameter	Outside Diameter	Empty Weight	Length	Working Pressure
	(liters)	( mm)	( mm)	(kg)	( mm)	(MPa)
CNG2-G-325-50-20B	50	325	340	47	815	20
CNG2-G-325-55-20B	55			50	880
CNG2-G-325-60-20B	60			53	945
CNG2-G-325-65-20B	65			56	1010
CNG2-G-325-70-20B	70			59	1075
CNG2-G-325-80-20B	80			65	1205
CNG2-G-325-90-20B	90			73	1335
CNG2-G-325-100-20B	100			79	1465
CNG2-G-356-55-20B	55	356	371	54.9	773	20
CNG2-G-356-60-20B	60			58.3	827
CNG2-G-356-65-20B	65			61.8	882
CNG2-G-356-70-20B	70			65.2	936
CNG2-G-356-75-20B	75			68.6	990
CNG2-G-356-77-20B	77			70	1012
CNG2-G-356-80-20B	80			72	1044
CNG2-G-356-90-20B	90			78.9	1153
CNG2-G-356-100-20B	100			85.7	1261
CNG2-G-356-120-20B	120			99.4	1478
CNG2-G-406-80-20B	80	406	421	79.4	864	20
CNG2-G-406-85-20B	85			82.6	905
CNG2-G-406-90-20B	90			85.8	946
CNG2-G-406-100-20B	100			92.2	1029
CNG2-G-406-120-20B	120			105	1194
