high quality Best Price and Different Specification Active Lime Rotary Kiln

Specifications

high quality Best Price and Different Specification Active Lime Rotary Kiln | high quality Best Price and Different Specification Active Lime Rotary Kiln

Introduction:

     Rotary kiln is the main equipment of calcining the cement clinker. The characteristics of a rotary kiln

are with simple structure, convenient and reliable control of the producing process,with little wearing parts

and high running rate. It is the equipment calcining the high grad cement in the cement factory. The rotary

kiln is widely used in the metallurgy,chemical industry,construction and other industries.

This series of rotary kiln is the large-size advanced international calcining kiln & furnace which is developed by our company and many scientific research institutes such as Beijing General Reserch Institute of Mining & Metallurgy, Changsha Research Institute Of Mining & Metallurgy, Suzhou Sinoma Reserch Institute of Non-metallic Mining Industry, etc. Compared with the rotary kiln with the same specification made by the traditional technology, this series of torary kiln can make the production capacity increase by 30%, make the heat consumption reduce by 40% and make the discharged flue gas temperature<250 °C , so it is convenient for collecting dust and meeting the modern environment protection needs about energy saving and consumption reducing. This rotary kiln is widely used for extracting nickel from laterite, calcining the activated limestone, oxidized pellet, magnesium oxide, aluminum oxide, titanium dioxide, etc.

 The structure chracteristic of ourcompany is:

1. The rotary kiln shell design fully take into consideration of the corner at shell flexible supporting to extend the lifetime of refractory bricks and castings.

2. Adopt supporing roller bearing with big diameter and small ratio between length and diameter to improve the reliability. The bearing is automatic self-sligning bearing.

3. The better sealing effect of new type open gear hood sealing type.

4. The spring lamination overlying type lexible sealing, double layer spring lamination sealing increase the heat insulation layer to improve the reliability and lifetime.

Main technic parameter :

The structure chracteristic of ourcompany is:

 This series of rotary kiln is the large-size advanced international calcining kiln & furnace which is developed by

our company and many scientific research institutes such as Beijing General Reserch Institute of Mining &

Metallurgy, Changsha Research Institute Of Mining & Metallurgy, Suzhou Sinoma Reserch Institute of Non-

metallic Mining Industry, etc. Compared with the rotary kiln with the same specification made by the traditional

technology, this series of torary kiln can make the production capacity increase by 30%, make the heat

consumption reduce by 40% and make the discharged flue gas temperature<250 °C , so it is convenient for

collecting dust and meeting the modern environment protection needs about energy saving and consumption

reducing. This rotary kiln is widely used for extracting nickel from laterite,  calcining the activated limestone,

oxidized pellet, magnesium oxide, aluminum oxide, titanium dioxide, etc.

 1. The rotary kiln shell design fully take into consideration of the corner at shell flexible supporting to extend

the lifetime of refractory bricks and castings.

2. Adopt supporing roller bearing with big diameter and small ratio between length and diameter to improve

the reliability. The bearing is automatic self-sligning bearing.

3. The better sealing effect of new type open gear hood sealing type.

4. The spring lamination overlying type lexible sealing, double layer spring lamination sealing increase the

heat insulation layer to improve the reliability and lifetime.

Parameters:

1 Specification: φ3.5×145m

2 Capacity: 700t/d (lime)

3 Slope of the kiln shell: 3.5%

4 Rotating speed of kiln (main driving): 0-1.38r/min

                   (Auxiliary driving): 0.043r/min (2.6r/h)

5 NO. of supporters: 6

6 Sealing type: sheet steel seal of kiln hood

7 Cooling type of kiln hood: air cooling

8 Driving type: Single driving

9 Type of thrust roller: hydraulic thrust roller

10 Cooling water consumption of each set of thrust roller: 2.5m³/h

11

12

13 Total weight (excluding kiln hood): 916t

             Weight of discharging kiln hood: 32t
