2500mm CNC 4-rollers Hydraulic Plate Rolling Machine,4 Roller Rolling Machine in China
Negotiable
/ Set
1 Set(Min. Order)
- chinese main port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
2000mm 4-rollers Hydraulic Plate Rolling Machine,4 Roller Rolling Machine, W12NC-20x2000 4-roller Machine
-
W12NC 4-roller Plate Rolling Machine, CNC W12NC-20*2500 Plate Rolling Machines With 4-Roller
-
CNC 4-roll Hydraulic Bending Machine,2500mm CNC 4-rollers Hydraulic Plate Rolling Machine
-
3000mm CNC 4-rollers Hydraulic Plate Rolling Machine,CNC 4 Rolling Machine
-
CNC 4-roller Hydraulic Rolling Machine,2500mm CNC 4-roll Hydraulic Plate Rolling Machine
-
2500mm CNC 4-rollers Hydraulic Plate Rolling Machine,4 Roller Rolling Machine, Hydraulic 4 Roller Bending Machine W12NC-16x2500
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | WENAO | Model Number | W12NC-16x2500 | |
| Machine Type | Roll Forming Machine | Raw Material | Sheet / Plate Rolling | |
| Material / Metal Processed | Stainless Steel | Power | Hydraulic | |
| Automation | Automatic | Extra Services | Heat Treating | |
| Certification | Other, ISO 9001:2000 CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
2500mm CNC 4-rollers hydraulic plate rolling machine,4 roller rolling machine in China| 2500mm CNC 4-rollers hydraulic plate rolling machine,4 roller rolling machine in China
MACHINE CHARACTERISTICS SL FOUR ROLLER ROLLING
CNC control system MACHINE TWO STRUC-
Leveling easily TURAL CHARACTERISTICS
Once circle forming Arc swing of the side roller,leverage increased
Large cone rolling more convenient pressure forces
Easy to correct the wrong edge Proportional valves on both sides of the roll syn-chronization
FOLLOWING USERS APPLY TO USE THE MACHINE
First use of the user,because this is one of the most easy-to-operate machine
Operators lack of inspection requires high productivity
Requires high accuracy,improving quality
Want only one operator,reducing labor costs
Due to the large size of the board,production of high or for security reasons require handling device,
Feeding plate form,side and upper feeding device
Want to use CNC operations,reduce operational personnel action levels and other factors.
| Model | Max.rolling | Max.pre-rolling | Plate | Diameter of upper roller | Main motor |
| thickness | thickness | width | power | ||
| mm | mm | mm | mm | kw | |
| W12NC-10x2000 | 10 | 9 | 2000 | 240 | 7.5 |
| W12NC-12x2500 | 12 | 11 | 2500 | 280 | 11 |
| W12NC-16x2500 | 16 | 13 | 2500 | 310 | 15 |
| W12NC-20x2000 | 20 | 16 | 2000 | 300 | 15 |
| W12NC-20x2500 | 20 | 18 | 2500 | 360 | 22 |
| W12NC-25x2000 | 25 | 20 | 2000 | 350 | 22 |
| W12NC-25x2500 | 25 | 20 | 2500 | 400 | 37 |
| W12NC-30x2000 | 30 | 25 | 2000 | 300 | 37 |
| W12NC-30x2500 | 30 | 25 | 2500 | 400 | 37 |
| W12NC-30x3000 | 30 | 25 | 3000 | 470 | 45 |
| W12NC-40x3000 | 40 | 32 | 3000 | 550 | 55 |
| W12NC-50x3000 | 50 | 40 | 3000 | 610 | 55 |
| W12NC-60x3000 | 60 | 50 | 3000 | 670 | 75 |
| W12NC-70x3000 | 70 | 60 | 3000 | 730 | 75 |
| W12NC-80x3000 | 80 | 65 | 3000 | 780 | 90 |
| W12NC-90x3000 | 90 | 75 | 3000 | 820 | 90 |
| W12NC-100x3000 | 100 | 80 | 3000 | 880 | 110 |
