Dry Ball Mill/energy Saving Ball Mill/industrial Ball Mill/wet Grinding Ball Mill

 cement ball mill

Our company has designed a new single-drive and double slide-shoe tube mill sliding shoe with bearing support structure which is used new and slide shoe support device, It is characterized by good lubrication, light weigh, easy to replace and easy to maintain.Type Y update sealing between slide-shoe housing and slide ring which is simple structure, better sealing performance.The mill gate of the cylinder is used outside cover and excellent structure, New type mill door, can make internal cylinder use the same specification lining plate.Specially equip with manhole lining plate like traditional way.Only use new classification lining plate and standard step lining plate.Increase the  grinding surface and have better classified efficiency.It is easy to maintenance and replace.New diaphragm structure is used adjustable lifting plate and fixed lifting plate, equip with one one material spoon which can increase feeding capability effectively, and the new structure is easy to install and maintain.

Scope of business:

The company has the great comprehensive ability to provide best quality services on turn-key basis with technology design, complete plant, erection and debugging,commissioning for the 10000t /d rotary kiln cement production enterprise.

    It can also undertake various projects abroad international bidding projects. It supplies complete equipments and technical services of grinding, calcination, crushing, dust collecting, conveying and lifting for the metallurgy, the chemical industry, the electrical power, the mine, the environmental protection enterprises, etc.

    The company has won the titles of Chinese leading enterprise in cement machinery industry, Jiangsu Credible and Trustworthy Enterprise and Jiangsu AAA grade credit enterprise. Its leading products have got Chinese famous brand products titles and "Pengfei" trademark also has been awarded "China Famous Trademark". The company covers an area of 350,000m2 and it has 0.82 billion RMB of total assets. There are 450 engineers and technicians. The company has the six subsidiary companies such as the mechanical plant, electronic plant, casting plant, installation plant, the new type building materials plant, etc.

    The company has the mechanical processing capacity of 300,000t/y; its rotary diameter and gear hobbing diameter are 10m as well as the diameter of the annealing furnace is 6.5m; the maximum hoisting capacity is 400t, so the company can meet the manufacturing requirements of the rotary kiln and ball mill below f6m. The large-sized pre-heater, rotary kiln, tube mill, vertical mill, cooler and other main machinery is completely researched, developed and manufactured by Nantong Wenao  itself.

dry Ball mill Series Main Technical parameters
