Home > Products > 904L DIN1.4539 UNS N08904 > 904L /254SMO /2205 / 2507 / 1.4529 threaded rods/full threaded stud bolts
904L /254SMO /2205 / 2507 / 1.4529 threaded rods/full threaded stud bolts
USD $0.1 - $10
/ Piece
20 Pieces(Min. Order)
- Shanghai
- T/T
You May Like
-
904L / 254SMO / 2205 /2507 stainless steel fasteners all threaded rods 1.4529
-
904L / 254SMO /1.4529 / AL6XN stainless steel fasteners spring washers DIN127
-
Stainless steel 904L bolts N08904 bolts EN 1.4539 bolts 254SMO S31254 EN1.4547
-
904L/254SMO /1.4529 /AL6XN hex special nuts and bolts fasteners
-
UNS N08904/904L stainless steel high strength hex bolt and nut washer 254SMO /F44
-
alloy 904L stainless steel stud bolts din975 /din976 F55 en 1.4539
Product Details
| Place of Origin | Jiangsu, China | Brand Name | X-DO | |
| Model Number | 904L threaded rods | Standard | DIN |
Product Description
904L /254SMO /2205 / 2507 / 1.4529 threaded rods/full threaded stud bolts
1.4539 (904L)
Material No. | 1.4539 |
EN symbol (short) | X1NiCrMoCu25-20-5 |
UNS | N 08904 |
AFNOR | Z 2 NCDU 25-20 |
alloy | alloy 904 L |
Normen | VdTÜV 421 , SEW 400 |
Description
Material 1.4539 (alloy 904L) is an austenitic special steel with high molybdenum content as well as addition of copper and extremely low carbon content.
Our product range in 1.4539(904L) are bolts and nuts, washers and threaded rods.
Chemical composition ¹ | ||||||||||||
C | Si | Mn | P | S | Cr | Mo | Ni | V | ||||
0,02 | 0,70 | 2,0 | 0,030 | 0,010 | 19,0-21,0 | 4,0-5,0 | 24,0-26,0 |
| ||||
Nb | Ti | Al | Co | Cu | N | Fe |
|
| ||||
|
|
|
| 1,20-2,00 | 0,15 |
|
|
| ||||
¹ in accordance with Key to Steel 2001 | ||||||||||||
Special characteristics | ||||||||||||
Temperature range: | Density kg/dm³ | Hardness (HB) | ||||||||||
pressure bomb/pressure vessel | 7,9 | ≤ 230 | ||||||||||
excellent stability against pitting corrosion, stress corrosion and intergranular corrosion | ||||||||||||
| Fastener Type | bolt&nut/screw/stud bolt//threaded rod/washer | |
| Bolt | Type | Hex head bolt; hex socket head bolt; square head bolt; U-bolt; T-bolt; round head bolt;Machine bolt; expansion bolt; CSK Head square carriage bolt; eye bolt; |
| Specification | Threads diameter: M6-M64. length: 10mm-500mm | |
| Standard | DIN931;DIN933;DIN975;DIN976;DIN915;DIN316;DIN444; DIN580; DIN916; DIN914; DIN913; DIN912 | |
| Screw | Type | hex screw; hex socket cap screw;hex socket countersunk head screw |
| Specification | M6-M64 length: 6-500mm | |
| Standard | DIN913; DIN912; DIN 7984;DIN 933; DIN84; DIN85; DIN7972; DIN694; DIN7971; DIN7973 | |
| Nut | Type | Hex nut;square nut; wing nut; weld nut; Coupling nut; Cap nut; flat nut; lock nut;half nut; full nut; |
| Specification | M6-M64 | |
| Machining | CNC turning, , CNC milling, CNC drilling and CNC boring by vertical CNC machine and Horizontal CNC machine | |
| Standard | DIN 934; DIN 439; DIN315; DIN985; DIN928; DIN929; DIN582; DIN6334; DIN917 | |
| Washer | Type | Plain washer; flat washer; spring washer;square washer; slant washer; wave washer |
| Specification | M6-M64 | |
| Standards | DIN125, DIN435, DIN9021, DIN433, DIN440R, DIN1440,DIN1441, DIN93, DIN7349, DIN1052, DIN988; DIN7603; DIN137A, DIN137B; DIN6769; DIN6797J; F436; DIN6798V; DIN 127B,ANSI18.21.1,DIN127A,DIN7980; DIN6798J;DIN6798A;ROUND WASHERS WITHOUT HOLE,BS4320 F/B,NFE25514Z/M/L/LL, IFI NARROW/WIDE | |
