Metal Tube Bend Making Machine
- shanghai or qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | NMB | Model Number | NMB-75CNC AS0022 | |
| Machine Type | Pipe and Tube Bending Machine | Raw Material | Pipe | |
| Material / Metal Processed | Stainless Steel | Power | Hydraulic | |
| Automation | Automatic | Extra Services | End Forming | |
| Certification | Other, CE,ISO9001:2008 | After-sales Service Provided | Overseas service center available |
wooden case or iron frame suitable for transportation
Product Description
Metal tube bend making machine :
Metal tube bend making machine Bending Machines Model NM75CNC
Introduction of our machine:
Our this kind machine can be classified into CNC pipe bending machine, hydraulic bender and other kinds. It is an equipment used to power construction, construction of roads and railway, boiler, bridge, ship, furniture, decoration and other fields that is related to the pipe laying and building. It has features of multi-function, reasonable construction,and easy operation. It enjoys a good market in the worldwide!
Features of our machine:
1. Fully automatic, is very easy to use and operate;
2. Equipped with 3 programmable axis;
3. Hydraulic pressure die assist for every bending stack;
4. Wiper, clamping and pressure die seats;
5. Centralized greasing system for moving areas;
6. Electric cabinet cooling fan;
7. Touch screen system
8. CNC 2 servo controlled axes with NC hydraulic bending
Technical parameter of our machine:
Model | NMB38CNC | NMB50CNC | NMB75CNC |
Max.bending ability(mm) | 38×1.5 A3 | 50×1.5 A3 | 75×1.5 A3 |
Range of bending radius (mm) | 25-200 | 35-200 | 50-280 |
Toptight formation(mm) | 55 | 65 | 100 |
Feeding accuracy(mm) | 0.1 | 0.1 | 0.1 |
Feeding speed(m) | 1.1 | 1.1 | 1.1 |
Max.bending angel | 185° | 185° | 190° |
Bending precision | 0.1° | 0.1° | 0.1° |
Bending speed°/sec | 65° | 44° | 24° |
Accuracy of angel | 0.1° | 0.1° | 0.1° |
Cormer speed°/sec | 120° | 120° | 120° |
Power source | 380V,50Hz | 380V,50Hz | 380V,50Hz |
Control valve voltageV | 2 | 24 | 24 |
Total power(KW) | 6.0 | 8.0 | 10.0 |
Oil Pump Power(KW ) | 4.0 | 5.5 | 7.5 |
Spare parts of our machine:
The spare parts of our machine include: forming die, pressure die,clamp die, wiper die(optional), ball
mandrel(optional).
Different shape of final products for your reference:
Metal tube bend making machine Bending Machines Processing type: pipe bender dies
Metal tube bend making machine Bending Machines Total power 6kw
Other pipe benders pictures of our factory:
Metal tube bend making machine Bending Machines Feeding accurance 0.1mm
Things need to be noted:
1.We design and manufacture the tooling according to the tube's specification, so the customers should send us the following tube's specification details: Tube's material and Outside Diameter, Wall Thickness, Bending Radius. THIS IS VERY IMPORTANT!
2. The Min./Max. bending radius could be made to order according the customer's special requirement.
3. The length over mandrel could be made to order according the customer's special requirement.
About our service:
If you are interested with our products, please contact us freely. We have a perfect after-sales service system, and also a professional team. So please be assured to buy our products!
Machine matched with pipe bender machine:
Metal tube bend making machine Bending Machines Opration type: CNC
Company Profile
Henan Name Brand Machinery Co.,Ltd are leading professional enterprise in China, we have our own specialized design, factory, research, marketing and after-sale teams. Our company machine can meet the international high quality standard, our machine are the newest generation base on the same industry .and most of our machine are the newest design, and can bring huge benefits for our end users. Henan Name Brand Machinery Co.,Ltd products 1, Food machines such as oil press, oil refinery, and different seeds complete line. Also with some other food machine such as potato machine, different plant seeder and Harvester, different nuts shelling machine, grain machines, donut machine, animal feed machine, fishmeal machine ,and vegetable and grain dryer machine, Etc related machines 2, Energy reuse and waste recycle machines such as Carbonization furnace machine, pellet machine, briquette machine, coal ball machine, charcoal machine, Copper wire recycle machine, crusher and some other matched dryer machines, Etc in China. 3, Industry heavy machine like crane Our machinery has many years of production history, and our products have been exported to clients from different more than 100 countries all over the world such as UK,USA,Italy,Mexico,Morocco,Benin,Indonesia,Malaysia,Pakistan,Vietnam,Korea,Canada,Tanzania,Egypt,Germany,Etc.We have won a good reputation among customers for good quality, competitive prices and advanced techniques. Our tenet is "taking the quality as life, taking the customers as god, and winning the credit standing and market by advanced manufacturing techniques, the best quality and services". We are looking forward to establishing business relationships with you in the near future.
