Home > Products > Die cutting machine > Automatic Hot Foil Stamping and Die Cutting Machine 1050Qlabel Die Cutting Machine
Automatic Hot Foil Stamping and Die Cutting Machine 1050Qlabel Die Cutting Machine
US$ 229,510 - 237,705
/ Set
1 Set(Min. Order)
- QINGDAO
- T/T
You May Like
-
2014 China Hot Sale High Speed Automatic Die Cutting Machine MWZ1650G
-
Flat Bed Die Cutting Machine China Famous Brand Hand Safe Guard
-
Used Die Cutting Machine China Famous Brand Hand Safe Guard
-
Rotary Die Cutting Machine China Famous Brand Hand Safe Guard
-
Automatic Hot Foil Stamping and Die Cutting Machine 1050Qdie Cutting Machine
-
Automatic Hot Foil Stamping and Die Cutting Machine 1050Q
Product Details
| Condition | New | Application | Apparel, Beverage, Commodity, Food | |
| Packaging Type | Cartons | Packaging Material | Paper | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 400V±5%, triphase, 50Hz | Power | 20KW | |
| Place of Origin | Shandong, China | Brand Name | Heng An | |
| Model Number | 004 | Weight | 15.5t | |
| Dimension(L*W*H) | 5050x4400x2440 mm | Certification | CE & ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
automatic hot foil stamping and die cutting machine 1050Q
Specification
Name | MZ1050 |
Max. paper size | 1050×750 mm |
Min. paper size | 400×360 mm |
Max. cutting size | 1040×730mm |
Max. cutting pressure | 300ton |
Stock range | Cardboard90-2000g corrugated board<=9mm |
Cutting pression | ±0.1mm |
Maxmechanical speed | 7500s/h |
Cutting rule height | 23.8mm |
Pressure adjusting range | 0-3mm |
Min. front margin | 10mm |
Inner chase size | 1140×756mm |
Tower power | 20kW |
Machine dimension | 5050x4400x2440 mm |
Total weight | 15.5t |
Control system | PLC control system |
Adjusting system | Frequency stepless speed regulation |
Electric power&voltage | 400V±5%, triphase, 50Hz |
Working environment temperature | -10℃~40℃ |
Humidity | Less than 50%@40°C or 90%@20°C |
Altitude | up to 1 000 m above mean sea level |
Air compressor displacement | 1.0 m³/min (motor power 7.5KW) |
Introduction
MZ1050 Automatic Die Cutting Machine(With full stripping) is special equipment which is suitable for high quality colored cardboard box creasing and die cutting. The machine adopts more advantages from other die cutters domestic and abroad.
About us
Our products cover a wide range from Two Star---Economic Type Platen Die Cutting Machine,Three Star---Semi Automatic Platen Die Cutting Machine,Four Star---Semi Automatic Platen Die Cutting Machine With Stripping,Five Star---Automatic Platen Die Cutting Machine,Six Star---Automatic Platen Die Cutting Machine With Stripping,Seven Star---Hot foiling die cutting machine, Automatic Embossing and Die Cutting Machine. the advantages of our products can process corrugated board as well as paperboard ,applied more widely, easy operation, stable function, safety& stability and so on.
Contact us
Contact Us
- Weifang Heng An Imp& Exp Co., Ltd.
- Contact nameyan li Chat Now
- Phone0086-0536-6103201
- AddressRoom 1210 no.2613 yuehe road ,kuiwen weifang city,shandong, Weifang, Shandong
