CE 8 Ton Excavator With YANMAR Engine
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | world | |
| Model Number | W285-8 | Condition | New | |
| Moving Type | Crawler Excavator | Operating Weight | 8250KG | |
| Bucket capacity | 0.36M3 | Maximum Digging Height | 7150mm | |
| Maximum Digging Depth | 4231mm | Machine Weight | 8500kgs | |
| Max Digging Radius | 2074/1791 | Certification | CE ISO | |
| After-sales Service Provided | Overseas service center available |
Product Description
8 ton excavator
| Model: W285-8 | 8.5 ton excavator with Air-conditioner | ||
| Bitmap | |||
| Engine System | |||
| Brand & Origin | Yanmar (Japan) | ||
| Model | 4TNV98T-SFN | ||
| Rated Power | 53.1/2200kw/rpm | ||
| Max. Torque | 286.9~312.7Nm/1000±100rpm | ||
| Idling Speed | 1000rpm | ||
| Engine Displacement | 3.318L | ||
| Cylinder No.-Bore/Stroke | 4-98mmx110mm | ||
| Engine Oil Capacity | 5.3-12L | ||
| Fuel Tank Capacity | 148L | ||
| Fuel Consumption Rate | 244g/kw.h or less | ||
| Hydraulic System | |||
| Main pump | Brand & Origin | Toshiba (Japan) | |
| Type & Model | PVC90RC08 | ||
| Rated Pressure | 27.5MPa | ||
| Nominal Displacement | 90 cm/rev | ||
| Multiple Unit Valve | Brand & Origin | Toshiba (Japan) | |
| Type | IB18-8027 | ||
| Rated Pressure | 27.5MPa | ||
| Hydraulic Motor | Travel Motor Brand & Origin | Jeil (Korea) | |
| Travel Motor Type & Model | JMV-53/31-01-VBC-RJ-47 | ||
| Traveling Speed (H/L) | 3.7/2.1 km/h | ||
| Swing Motor Brand & Origin | Toshiba (Japan) | ||
| Swing Motor Type & Model | SG025E-136 | ||
| Swing Speed | 11rpm | ||
| Hydraulic Cylinder | Brand & Origin | Hengli (China) | |
| Boom Cylinder Specifications | 110mmx75mm | ||
| Arm Cylinder Specifications | 100mmx65mm | ||
| Bucket Cylinder Specifications | 90mmx55mm | ||
| Hydraulic Oil Tank | Capacity | 112L | |
| Working Specifications | |||
| Weight | 8250kg | ||
| Bucket Capacity | 0.36m3 | Bitmap | |
| Bucket Width | 755mm | ||
| Bucket Digging Force | 63kN | ||
| Arm Digging Force | 50kN | ||
| Ground Pressure | 37KPa | ||
| Grade Ability | 70% | ||
| Max. Digging Depth | 4231mm | ||
| Max. Digging Height | 7150mm | ||
| Max. Digging Radius | 6802mm | ||
| Max. Discharging Height | 5139mm | ||
| Min. Ground Clearance | 367mm | ||
| Min. Swing Radius | 2074mm/1791mm | ||
| Overall Dimensions(LxWxH) | 6502mmx2320mmx2601mm | ||
