High Power professional 850nm laser diode module

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Port FOB shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	sh
Model Number	SH-T-532-500	Type	Laser Diode
Package Type	Surface Mount

Product Description

Specifications

High Power professional 850nm laser diode module
*Freezing point direct hit
*non rebirth, no pain

High Power professional Diode laser

High Power professional 850nm laser diode module

500mW 532nm DPSS Green Laser
Model: DHOM-T-532-500

Item Description

All of our DPSS lasers are manufactured by DHOM (Suzhou Daheng Optics & Fine Mechanics Co., Ltd.), which is one of the largest manufacturers in China specialized in DPSS lasers.

These lasers have built-in TEC in order to maintain constant temperature, and the input voltage is from AC 100V to 260V, to make it safe to be used in any of countries.

TTL or analog modulation interface is avialiable and standard power supply is also well designed and produced in high quality. All of our 532nm DPSS lasers have passed CE adn RoHS authentication.

Every DPSS laser is tested strictly before it is shipped to our worldwide customers.
Features: high stability (< 5%), excellent cooling, utra compact, small divergence ...

Specifications:

Model Number: DHOM-T-532-500
Wavelength: 532nm
Output Power: > 500mW
Input Voltage : AC 90 - 260V
Operating mode: CW
Cooling mode: TEC & Fan
Transverse mode: TEMoo
Beam Diameter at the Aperture: ~ 2.0mm
Divergence , full angle: 2.0mrad
M² Factor: < 2.0
Power Stability (RMS/4 hrs): < 5%
Operating Temperature: 10~35 degrees C
Modulation Mode: Analog ( 20KHz )
Dimensions of Laser Head (L x W x H): 130mm x 54mm x 40mm
Power Supply Unit Model:
OEM-40B ( 105mm x 61mm x 56.1mm )
Expected lifetime:
10,000 hours
Warranty Period: 1 year
