QT4-15 Vibration Concrete Block Making Machine,automatic Hollow Block Machine
- Qingdao
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
-


Ceramic Tile Making Machinery Qt4-15 Shengya Machinery Group
 -


Concrete Block Making Machine QT6-15 for Building Material
 -


Fully Automatic QT8-15 Auto Paver Block Making Machines
 -


QT8-15 Automatic Hydraulic Pressure Hollow Brick Paving Block Making Machine
 -


QT10-15 Automatic Hollow Concrete Block Forming Machine
 -


QT10-15 Sand Cement Concrete Block Making Machine Production Line Installed in Saudi Arabia

Product Details
| Condition | New | Type | Hollow Block Making Machine | |
| Brick Raw Material | Concrete | Processing | Brick Production Line | |
| Method | Hydraulic Pressure | Automatic | Yes | |
| Capacity | 9600pcs/8h | Place of Origin | Shandong, China | |
| Brand Name | Shengya | Model Number | QT4-15 | |
| Voltage | 380V | Power | 29.4kw | |
| Dimension(L*W*H) | 3700*1500*2600mm | Certification | CE/SGS/ISO9001 | |
| Warranty | 1 Year | After-sales Service Provided | Overseas service center available |
Product Description
QT4-15 Vibration concrete block making machine,automatic hollow block machine
The youtube website of video:https://youtu.be/cDkgSZvmtvs
QT4-15 block making machine is completely controlled by PLC system .By operating its computer interace,the random signal analysis,fulat diagnosis and parameter setting up of all kinds of materials can be achieved easily.
the material stock hopper and the material feeding hopper are separated ,toeach other ,for the purpose of quantitative feed of material,which can effectively control the advance liquidation of some concrete and reduce the feeding time.
its unique material feeding device can quikly and evenly discharge the materials into the moulding box so that the weight error in finished products can be reduced to the minimum.
for its frame structure ,super strong shaped steel bars are used ,for its electronic and hydraulic systems, most the important elements are impored ,so all of these have ensured the stability and reliability of the machine in long term of opration.
this machine has good applicability.it not only can be used for producing concrete blocks of high strength,but also for pulverizd coal ash bricks ,cinder bricks,mine slag, and so on.only by changing different moulds and dies ,the hollow blocks and solid blocks of different specifications can be manufactured.
The host machine:
Popular used block samples:
We have our own long cooperate shipping company, they can offer the best freight. And if you would like,we can use your shipping company to sent the machines.
Packaging:steel box or bulk
Shipping:   qingdao port ocean shipping
Delivery time: 20days after 30% deposit
Shandong Shengya Machinery Co.,LTD. was founded in 1995, We have been always working for the concrete block machines and mixers design, production and sales. For many years we have to perfect the quality, export block machines to more than 90 countries and regions, and also have office inNigeria, Tanzania,Algeria, Ethiopia,Kenya,Cameroon,and Indonesia now, then can serve the clients much better.
Our factory:
Certification:
1,Why choose us?
20 years' manufacturing experience of brick making machine.
8 after-sale servicing offices in Africa.
More than 20 mechanics provide after-sale service at abroad
2,What kind of the brick that the brick making machine can produce?
All kinds of the hollow block and paving brick.
You can customize the type of brick.
3,what is the driving power of the hollow block making machine?
Electricity and diesel engine
4,What is the material of the brick?
cement,sand,stone.fly ash,building waste and so on.
My customers with me in the canton fair:
