suspension concrete Pipe Making Machine--manufacturer

  reinforced concrete pipe/making machine is the ideal equipment to manufacture cement pipe. Reasonable design, reliable and simple operation, accord with state standard GB11836-89. The machine can be produced different sizes of tubular products such as connection tubes, small tubes and large tubes of inner diameter of 200-1000 mm by using sand, gravel, stone chips, fly ash and slag mixed with appropriate amount of cement.

1 Short production Cycle: because of the good effect of the roller to compact the concrete, every pipe just need 1-10 minutes with high speed roller rotation.

2 This Pipe machine use the dry cast material, there will no waste cement mud, then it wont pollute the environment.

3 During the production, the noise is low, it is about 80-90 DB

4 The Concrete Pipes are with high pressure load and with high production efficiency.

This machine use the Roller to support the pipe mould, and produce the roller force to concrete in the mould. When the roller rotate at a high speed, the concrete in the mould will spread in the inner wall of the pipe mould and form a cement pipe with the centrifugal force, and when the mould with the inner concrete pass on the roller,the concrete between the mould and the roller will be compacted solid to form a pipe.

1. Commitment to quality  and one year guarantee for main body.

2. We arrange engineer to supervise installation, make the load test, do commissioning, train of the buyer's workers.

3. Customer service 24 hours per day, 7 days per week.

4. Technique support: for any time, any way.
