stacking machine manual stacker for sale

FOB Price

USD $10,000 - $38,960 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	GOLE	Model Number	260EC6
Type	Powered Pallet Truck	Power Souce	Diesel Engine
Rated Loading Capacity	9000kg	Max. Lifting Height	16830mm
Min. Lifting Height	2m	Fork Length	9800mm
Fork Width	6100mm	Overall Dimensions	684041354400
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

stacking machine manual stacker for sale

Product Description

Features of Stacking Machine:

1. Door frame with two type, designed to slot in each stacking height, internal and external door frame beams overlap to achieve

the maximum degree of assurance the driver's field of vision.

2. Drive axle produced in Germany KESSLER drive axle. The bridge design is reasonable, axle housing, high strength, load capacity,

safety and reliability, long service life.

3. Automatic transmission, back protection, synchronizer; with neutral gear ignition and micro-features.

4. Using the Swedish VOLVO TAD 720VE engine, low noise, low fuel consumption, emissions in line with European standards on the 2nd

5. Spreader with a lateral feature, making operation more flexible and convenient, saving cycle time hanging box.

6. Equipped with the world's most advanced variable piston pump and load-sensing valve load sensing system.

Item		260EC6
Rated Payload	Kg	9000
Max. Layers of Stacking		5×9'6'' 6×8'6''
Mast Tilting Angle(Forward/Backward)	°	2°/4°
Max. Travel Speed (with Load)	Km/h	28
Max.Lift Speed(with/without Load)	mm/s	630/730
Max. Lowering Speed (with Load)	mm/s	600
Max. Gradeability (with Load)	%	28
Min. Turning Radius	mm	6050
Front Axle Load (with/without Load)	Kg	40700/27700
Rear Axle Load (with /without Load)	Kg	7800/11800
Max.Traction Force	KN(2Km/h)	128
Operating Weight	Kg	39500
Number of Wheels (Front/Rear)		4/2
Tire Type		14.00-24-28PR
Engine Manufacturer / Model		VOLVO TAD 720VE
Rated Power	KW(hp)/rpm	174(237)/2300
Peak Torque	Nm/rpm	854/1400
Transmission		DANA(CLARK) TE17
Gear(Foward/Reverse)		3/3
Axle		KESSLER D81
Fuel Tank Volume	L	400
Hydraulic Oil Tank Volume	L	430
