Large Capacity and Higher Lifting Height Diesel Telescopic Forklift
- QINGDAO
- T/T Credit Card
You May Like
-
High Quality and Easy to Operate Used Forklift
-
1T Full Automatic High Lifting Height Forklift Price Forklift Battery for Sale
-
Stacking Machine Manual Stacker for Sale
-
1T Safety to Operate Electric Forklift New Forklift Price
-
Electric Forklift / Forklift Parts With 175mm Front Overhang for Sale
-
3 Wheels Electric Forklift With Great Value for Sale
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | GOLE | Model Number | GLCZJ03 | |
| Type | Powered Pallet Truck | Power Souce | Diesel Engine | |
| Rated Loading Capacity | 3000kg | Max. Lifting Height | 4m | |
| Min. Lifting Height | 2m | Fork Length | 1070mm | |
| Fork Width | 120mm | Overall Dimensions | 6340*2120*2390 | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
large capacity and lifting height diesel telescopic forklift
Technical Parameter:
- Max lifting load: 3000kg
- Max lifting height: 8500mm
- Max lifting load capacity under Max lifting height: 2000kg
- Max length of overhanging in Horizontal position: 4580mm
- Load capacity of Max overhanging in Horizontal position: 1000kg
- Wheel Tread: Front 1460mm ;Rear 1750mm
- Wheel Base: 2600mm
- Total Weight: 7500kg
- Overall Dimension (with fork): 6340mm*2120mm*2390mm
- Overall Dimension (without fork): 5160mm*2120mm*2390mm
- Engine Model: Quanchai4JR3ABG18
- Rated Power: 60/220kw/r/min
(1) The flow of goods logistics industry in the processing of storage, handling, transport links.
(2) Industrial waste collection, transportation, storage and pretreatment industry.
(3) The drying of crops in rural areas, collection, packaging, storage and processing operations.
(4) Small rural soils, rock engineering.
(5) Outdoor projects, facilities and equipment installation.
(6) Roads, municipal engineering, telecommunications and electricity facilities, equipment installation.
(7) Stone plate, stone product container loading and unloading in stone circulation fields.
(8) The material handling and equipment maintenance in factories and enterprises.
(9) Cabin materials handling operations.
(10)Maintenance of trees in garden business.
Description Model No |
GLCZJ03 |
Rated Capacity (KG) | 3000 |
Max Lifting height (m) | 8.5m |
Total weight (KG) | 7500 |
Overall dimensions with fork (mm) | 6340*2120*2390 |
Material of Telescopic Boom | 700 high strength steel plate |
Material of other parts | Q345B |
Engine Brand | Quanchai Diesel |
Engine Model | Quanchai 4JR3ABG18 |
Power (kw/r/min) | 60/2200 |
Max torque | 9 T.M |
Length( m) | 1.15M |
Width Thickness (mm) | 120mmX(Front 10mmX Rear50mm) |
Max distance between forks (m) | 1.0M |
Transmission system | Hydraulic Transmission |
Number of speed | 3 |
Max travel speed (km/h) | 20KM/h |
Gradeability | 0-15° |
Gear pump with capacity at max. speed | TDX40N |
Max. working pressure | 16MP |
Multi-way valve | TRM20-BX-07-YG |
Hydraulic oil (L) | 130 |
Fuel (L) | 100 |
Engine coolant (L) | 30L |
Engine oil (L) | 4L |
Color | Can according to the customers’request |
