Deep freezer Cold Chain Equipments Monitoring System 7-days Temprature Recorder

  Cold Chain Equipments Monitoring System 7-days Temprature Recorder Chat Temperature Recorder

Applicable to blood bank refrigerators, medical, low temperature, and ultra low temperature units.

Characteristics of the product function:

• The product mainly applies to blood bank refrigerators, ultra low temperature freezers and

          other medical equipment that requires temperature recording over time.

• The record chart paper is circular. Reading of temperature is simple and reliable. The

           operation of the unit is rather straightforward.

• The unit is designed to operate with a precise microchip to ensure an accurate and reliable

           recording of time.

• The recorder is also designed with a special circuitry to protect the operation of the motor

           from external electronic disturbance.

     Ambient conditions

        Please perform operation under the following conditions in order to ensure accuracy.

• Indoor use;
• Elevation above sea level ≤ 2,000m;
• Ambient temperature within -10°C ~50°C;
• Ambient humidity within 0% ~ 90% RH;
• The fluctuation of voltage of the main power supply without exceeding the rated voltage.

  Technical parameters

Main parameters

a) Range of test temperature:

-40°C~+30°C, resolution: 1°C;

-115°C~+50°C, resolution: 5°C;

-200°C~0°C, resolution: 5°C;

b) Temperature and humidity of working environment: -10°C ~50°C and 0 ~90% RH;

c) Recording time cycle: 7 days or 24 hours;

d) Working power supply: AC 100V ~240V and 50 Hz or 60 Hz;

e) Rated power: ≤8W;

f) Installation method: Mosaic installation on the wall;

g) Back-up battery: Lithium Battery(When the battery is fully charged, it can run the recorder for at least 24 hours.)

Feature Product for Your Reference

Packaging Detail : By export wooden carton outside and pallet at bottom for Deep Freezer.

Delivery Detail      :15-45 workdays
