k Cup Filling Machine/k Cup Sealing Machine/k Cup Filling and Sealing Machine

k cup filling Machine/k cup sealing machine/k cup filling and sealing machine

Working procedure:

The machine adopts pneumatic driven working principle. PLC control can maintain the consecutiveness and stability of the machine. You just input the indications into the PLC.

The whole procedure is as follows:

Automatic cup dropping----automatic paste filling ----sealing the container with photocell to trace the design of your film in roll to make sure the design of the film in the middle of the container cover(coding system is included, when seal the container the installed ribbon coder will print date or something else to the cover film )----automatic cutting of the rest film----absorbing the outer cap then press the outer cap to the container

Detailed machinery introduction:

1.The main parts of the machinery is made up of high quality Stainless steel 304.

2.The sealing head is made of Copper TEFLON.

3.The cutter for the film is 23# standard knife for operation used in hospital (circling knife slices).

4. Pneumatic groupware is Taiwan Brand YA DE KE

5.The main body of the machine is A3# steel board

6. The mould is made up of casting Aluminum.

7. The whole machine is controlled by PLC, very easy to operate.

Technical Parameter:

1.      Machine dimension: 4000*700*1450

2.      Voltage: AC 220V,50HZ

3.      Power: 4KW

4.      Air pressure: 0.85/0.75  (7.5KW Motor)

5.      Capacity: customized

We still have 4-line, 6-line, 8-line, 10-line, 12-line machine to meet your different speed requirement

6.      Net Weight: 900KG

Further information to be confirmed with clients:

1. Products to be filled into cups: liquids/paste/jelly

2. Cup shape & specifications  (diameter*height)

3. Desirable speed: cups per hour( we have 2/4/6/8/10/12 lane machine)

Standard Export Packing for aerosol products/air freshener/insect killer filling machine or production line

1.Cover by PVC film + fumigated wooden case;

2.Wooden case suitable for long distance ocean shipping.

 After-sales service

We guarantee the quality of the main parts within 12 months. If the main parts go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After one year, if you need to change parts, we will kindly provide you with the best price or maintain it in your site. Whenever you have technical question in using it, we will freely do our best to support you.

 Guarantee of quality

The Manufacturer shall guarantee the goods are made of Manufacturer’s best materials, with first class workmanship, brand new, unused and correspond in all respects with the quality, specification and performance as stipulated in this Contract.

 Installation and Debugging

The seller would dispatch his engineers to instruct the installation and debugging. Cost would be bear on buyer’s side(round way flight tickets, accommodation fees in buyer country). The buyer should provide his site assistance for the installation and debugging.V

Shanghai Shouda Packaging Machinery & Material Co., Ltd., which has over 15 years' experience, is a professional manufacturer of automatic packaging machineries & automatic filling and packing production line for liquid, gel, aerosol product.

Shouda has passed CE certificate Standard of EU and meet the requirement of GMP. The company has gained wide reputation with the immediate and perfect round-the-clock service provided by senior engineers. Please bear in mind that Shouda will make you moved at the same time.

Photos of factory

Certificate

 Our business involves various markets all over the world, in many fields with our excellent product performance.

1.Q:Are you a manufacturer or a trading company?

 A:We are the manufacturer with over 16 years experience.

 2.Q:What's the payment terms?

 A:T/T,30% deposit and 70% balance before delivery.

 3.Q:How to order?

 A:You can send me an inquiry,then we could confirm the details through emails or telephone.

 4.Q:How much is the transportation freight?

 A:The freight depends on the weight and size,also the destination port

 our video  link :

/watch?v=ooPRkq8FKGY

Pls contact us
