china liquid packaging filling and sealing machine on sale

This machine adopts PLC programmable control, with the LCD touch screen man-machine interface system, the normal pressure fixed flow channel parameters, control the filling time to achieve different metering filling. The device has the advantages of simple structure, and the size of the bottle can be used for changing the shape of the bottle without changing parts. Widely used in such as juice, soy sauce, vinegar, mineral water, pesticide, chemical, detergent, oral liquid, disinfectant, lubricating oil and cosmetic liquid filling. Filling measurement accuracy, no bubble, no leakage. Can be applied to 40-1000ml all kinds of bottle shaped (including special shaped bottle) filling.

Advanced technology

1, the machine is suitable for different specifications of the container filling, can be switched within a few minutes filling specifications.

2, filling cycle is short, high production capacity.

3, replace the filling specifications without adding equipment, just make adjustments to complete.

4, touch operation screen, can display the status of production, operating procedures, filling etc..

5, each filling head is provided with a clamping device, ensure the bottle feeding accurate.

Unique filling method

1, the design of the straight line type into the bottle, the bottle out of the way, so that filling function expansion, each

All kinds of containers can be effectively filled in this equipment.

2, the gas filling valve international advanced filling process, ensure no leakage and no vertical birth.

3, strong PLC software support, can achieve the ideal filling operation.

4, friendly man-machine interface, so the operation was completed in the touch screen.

Precise metering control

1, filling with fixed flow channel parameters, control filling time, realize different measurement of filling.

2, pneumatic valve filling the precise time can be set to 0.01 wonderful, can make the measurement accuracy control

In the 1% error range, reduce unnecessary material loss, improve the economic efficiency of the user.

3, the measurement of each filling head can be adjusted separately, in order to achieve the consistency of filling measurement.

4, the machine set up into the counting process, no bottles, counting is not in place is not filling, only when

The number of bottles recorded by the counter is in agreement with the number of the set number of bottles.

5, the number of filling amount, can be carried out at the beginning of the required filling amount, and then fine-tuning,

Ideal filling measurement accuracy can be obtained.

main parameter

Name: in-line filling machine (with diving device)

Model: AT-L8

Measurement range: 40-1000ml

Filling accuracy: + 1%

Production capacity: 0-3000 bottles / hour

Gas source pressure: 0.5-0.7mpa

Gas consumption: 200L/t

Power supply: 50Hz 380V

Total power: 0.8KW

Weight: 400kg

Size: length * width * height (6000 * 850 * 2600) mm
